FRONT PANEL

Phones jack to monitor the signal. Headphones volume can be adjusted in two methods:

1 - Using the UP and DOWN buttons in the home screen;

2 - Through the front panel navigational menu:

Settings > Audio / MPX Outputs > Phones Volume.

– The RF LOSS will be indicated whenever the level of the RF signal drops below the selected

threshold. The RF LOSS detection threshold and time can be set trough:

Settings > Tuner > RF Loss Threshold / RF Loss Timeout

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com

- 22 -
