OUTPUTS
Composite
Audio (L, R)
AES3 (L, R)
SPDIF (L, R)
Optical (L, R)
Alarms
Headphone
COMMUNICATION INTERFACES
USB
Ethernet 10/100 Base-T
GSM Modem
MEASUREMENT STORAGE
Storage
Data format
POWER
Supply
Connector
SIZE AND WEIGHT
Dimensions (W;H;D)
Shipping Weight
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com
3.5 Vp-p @ 75kHz, 75Ω, unbalanced BNC Connector
+12 dBm, 600Ω balanced XLR Connector
5.0 Vp-p, 110Ω , balanced XLR Connector
3.0 Vp-p, 110Ω, unbalanced BNC Connector
Transmitter, TOSLINK
Programmable terminals on rear panel, optoisolated
6,3mm (1/4") Phone Jack
B-type Connector
RJ45 Connector
15 pin Male D-Sub Connector
2GB Build-in Memory Card
Text, CSV
100-240V / 50-60 Hz / 25W
IEC320
485 x 44 x 180 mm, , 19" x 1.7" x 6.9"
3kg, 7lb
- 10 -
