- Page 1 USER MANUAL GSM Modem Option Compatible with: DB44, DB45, DB4004, DB7000, DB7007 Publish Date: 06-Mar-2018...
- Page 2 - Sierra Wireless AirLink. This is the modem that is provided from DEVA Broadcast if the feature has been ordered along with the DEVA Unit. The GSM modem model is directly PIN to PIN compatible with the DEVA Unit GSM Modem’s connector, and by simply using a direct cable, you will have not any troubles with the data communication and audio insertion.
- Page 3 65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com SHORT MESSAGE SERVICES AVAILABLE • By sending, a message with the command Listen + the desired station (for example “Listen 101.80”), the DEVA Unit will retrieve you a call with short record of the station that you have required.
- Page 4 65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com REMOTE STATUS REQUEST The DEVA Unit can send you a report with the values of the most important FM Parameters like RF level, MPX Level, Pilot Level, RDS Level, L&R Audio Level, Stereo/Mono Status and RDS PI Code at any time.
- Page 5 INITIALIZATION PROCEDURE FOR SIERRA WIRELESS AIR- LINK FXT009 GSM MODEM in regards with the following DEVA Units: - DB44 – Compact FM Radio Monitoring Receiver - DB45 – DSP-Based FM Radio Receiver and Modulation Analyzer - DB4004 – DSP-based FM Radio Monitoring Receiver - DB7000 –...
- Page 6 65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com Upon powering on, the modem should start working with its factory settings. To see these settings type the command “AT&V”. The modem will respond with the factory default settings: Q:0 V:1 S0:000 S2:043 S3:013 S4:010 S5:008 +CR:0 +CRC:0 +CMEE:0 +CBST:0,0,1 +SPEAKER:1 +ECHO:0 &C:0 &D:2 %C:0...
- Page 7 65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com 2. Connecting with DEVA Unit Communication Cable Description: DEVA Unit port GSM modem Note DB 15 female DB 15 male –> com TX –>...
