IP address (IP). Represents an IPv4 address.
Example:
IP mode, front panel buttons usage:
Left/Right - Select edit marker position;
Up/Down – Cycle through the possible values;
OK - Accept the changed value and exit edit mode;
SB4 – Discards all changes and cancels edit mode.
IP port (PORT). Represents TCP or UDP port.
Example:
IP port mode, front panel buttons usage:
Refer to "IP mode, front panel buttons usage".
RDS Program Identification (PI). Represents RDS Program Identification.
Example:
RDS PI edit mode, front panel buttons usage:
Refer to "IP mode, front panel buttons usage".
Date (DATE). Represent date from the calendar.
Example:
DATE mode, front panel buttons usage:
Left/Right – Selects previous/next segment from the date;
Up/Down – Cycle through the possible values;
OK – Accept the changed value and exit edit mode;
SB4 - Discards all changes and cancels edit mode.
Time (TIME). Represent time information.
Example:
TIME mode, front panel buttons usage:
Refer to "DATE mode, front panel buttons usage".
Timer (TIMER). Represents relative time interval.
Example:
TIMER mode, front panel buttons usage:
Up/Down – Increments/decrements value with one step. The unit value will be changed
automatically from seconds to minutes and vice-versa;
OK - Accept the changed value and exit edit mode;
SB4 - Discards all changes and cancels edit mode.
String (STR, EMAIL, TEL, HOST). Represents string.
Example:
STR mode, front panel buttons usage:
Left/Right – Select edit marker position. If Right button is pressed when the marker is at the last
character, a space character will be added at the end of the string. When the Left button is pressed
all trailing spaces will be removed;
Up/Down – Cycle through the possible values. Depending on the string context there is a limitation
in the permitted char set. For example phone number string can contain only "1234567890+" and
blank space characters;
OK – Accept the changed value and exit edit mode. Some Strings, like e-mail addresses, must
pass a validation check. If the validation fails, message box will appear. Press OK to dismiss the
