Appendix 2: List Of Db7000 Settings - DEVA Broadcast DB7000 Maintenance And Operating Instructions

Parameter Name Type
Tuner
Frequency INT
RF Input ENUM
Attenuator Ant 1 ENUM
Attenuator Ant 2 ENUM
Frequency Step ENUM
IF Bandwidth ENUM
Stereo Blend ENUM
High Cut ENUM
High Blend ENUM
Soft Mute ENUM
Audio Cut ENUM
Deemphasis ENUM
RDS Mode ENUM
PI Protection ENUM
PI PI
RF Loss Threshold INT
RF Loss Timeout TIMER
Average and Peak
Attack Time INT
Release Time INT
Peak Hold INT

APPENDIX 2: List of DB7000 settings

Range
87.1 ... 108.1, step 0.05
Antenna 1, Antenna 2
Auto, OFF, -10dB, -20dB, -30dB
Auto, OFF, -10dB, -20dB, -30dB
10, 20, 50, 100, 200
27, 36, 45, 53, 62, 71, 79, 88, 97, 105, 114, 123,
131, 140, 149, 157, Auto
Auto, Off
Auto, Off
Auto, Off
Auto, Off
5, 10, 15, Off
FLAT, 50, 75
RDS, RBDS
Enable, Disable
0 ... 110, step 1
1 ... 60, step 1
0 ... 500, step 10
50 ... 1000, step 10
500 ... 5000, step 500
Default value [, Unit]
98.1, MHz
Antenna 1
Auto
Auto
50, kHz
Auto, kHz
Auto
Auto
Auto
Auto
Off, kHz
50, µs
RDS
Disable
40, dBµV
1, s
50, ms
500, ms
1500, ms
- 70 -
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: +359 56 820027, Fax: +359 56 836700
E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com
Description
Tuner related submenu
Currently set frequency
Active RF antenna input
Attenuator setting for antenna input 1
Attenuator setting for antenna input 2
Step for frequency tuning
IF filter bandwidth
Stereo blend level
High cut level
High blend level
Soft mute level
Audio cut level
De-emphasis settings
RDS decoder mode
PI Protection Enable
PI Protection code
RF threshold level
RF timeout
Signal averaging related submenu
Attack time for signal measuring
Release time for signal measuring
Peak hold time
