OTHER SETTINGS SCREEN

To update the device firmware, select the new firmware file. After having pressed the Upload

button, a dialog window will appear. Confirm the firmware update and wait for the process to

complete. Information on current DSP1, DSP2 and WEB version is also found in this section.

Information about the device storage space is found in this section. The entire internal storage

could be deleted by pressing the 'Format' button.

By pressing the 'Clear' button, all records in the System log will be deleted.

•

All except IP – all settings, except for the Network settings (IP Address) will be deleted;

•

Channels – all settings applied to the channels of the Logger and the RDS PI/RBDS Call

campaign will be switched back to the factory defaults.

To restore DB4004 to its Factory Defaults you should first select the desired option and then

press the relevant button. A new window will appear – confirm that you want to restore the factory

defaults and wait for the process to be completed. On completion of the process, the settings

should have the proper default values.

To start Rebooting of DB4004, press the Reboot button. A dialog warning window will appear.

Confirm that you want to reboot the device and wait for the process to be completed.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com

- 72 -
