Main screen working area

The Main part of the OLED Screen is where the information changes dynamically, depending
on the selected working mode. The Menu Screen (shown below) appears upon pressing of the
"OK" Navigational Button. The DB7000's Menu Page contains selectable icons and software
buttons for selecting modes and functions. Pressing Left and Right arrow buttons will change the
icon selection on the Menu Page. The current selection is shown as rectangle focus frame around
the icon. Pressing "OK" button will navigate to the corresponding page.
The following Operating Modes and Pages can be selected using the Navigational Buttons:
- Home page;
- Bandscan page;
- Levels page;
- Graphs page;
- Settings page;
- Status page;
- About page;
- RDS Decoder page.
