Settings Menu screen structure

Settings menu title

– shows the path to the currently selected menu. Note that the parameter should be included in
the settings menu title.
For example: Settings > Communication > Application - Port is different
from Settings > Communication > HTTP - Port.

Navigation area

– selection of branches / parameters is made in this area. The selected item is highlighted. All
parameters are listed on the left side of the navigational area. All parameter values are displayed
on the right side against the parameter name. Since branches have no values associated, tree dots
are shown instead. This indicates that a transition to a sub-menu is available.
Front panel buttons usage:
OK – Depending on the selected menu element can perform different actions:
•
Menu branch – transition to selected sub-menu will be made;
•
Menu parameter – when a value of a parameter is highlighted pressing OK will switch to
edit mode;
•
Menu complex parameter (such as Alarm) – the parameter editor screen will be shown.
Up/Down – If edit mode is active, the value of the selected parameter will be changed. Otherwise,
are used for navigation through the menu;
Left/Right – Change the selection when the parameter value is in edit mode;
SB4 – Return one level up or cancel edit mode.
There are several parameter types available in DB7000. The way of editing depends of the
parameter type. Every parameter type has its own editing rules.
Numerical parameter (INT). Represents numerical value.
Example: The value frequency can be changed in the range of 87.10 to 108.10 MHz and step
of 10, 20, 50 or 100 kHz.
INT mode, front panel buttons usage:
Up/Down - Change the value of the parameter with one step. The step value may vary depending
on the selected parameter. The value always stays in permitted parameter range;
OK -Accept the changed value and exit edit mode;
SB4 will discard the value and cancel edit mode.
Enumerated parameter (ENUM, TZONE). Represent the selection of a value among set of
predefined enumerated values.
Example: The value Attenuator can be selected from "Auto", "OFF", "-10dB", "-20dB" and
"-30dB".
ENUM mode, front panel buttons usage:
Up/Down – Cycle through the possible values;
OK - Accept the changed value and exit edit mode;
SB4 will discard the value and cancel edit mode.
