ini and Auxiliary Files Descriptions
Table 13
File Type Description
Ini Load this file to provision the device's parameters. The Embedded Web Server enables
practically full device provisioning but customers may occasionally require new feature
configuration parameters in which case this file is loaded.
Note that loading the ini file only provisions parameters that are contained in the ini file. If a
parameter is not specified in the ini file, values associated with that parameter are reset to a
default value. These values may not be the same as the values that were configured for the VoIP
gateway at the time of manufacture.
Note: After the file has completed loading, the VoIP gateway automatically restarts (software is
loaded from the flash).
Coefficient This file (different file for FXS and FXO gateways) contains the telephony interface configuration
information for the VoIP gateway. This information includes telephony interface characteristics,
such as DC and AC impedance, feeding current and ringing voltage. This file is specific to the
type of telephony interface that the VoIP gateway supports. In most cases you have to load this
type of file.
The voice announcement file contains a set of Voice Prompts to be played by the VCX V7111
Voice Prompts
during operation on Call Agent request. Only MGCP is supported.
Call Progress Tones This is a region-specific, telephone exchange-dependent file that contains the Call Progress
Tones levels and frequencies that the VoIP gateway uses. Default CPT file: U.S.A.
The dat PRT file enhances the device's capabilities to play a wide range of telephone exchange
Prerecorded Tones
tones.
To load an auxiliary file via the Embedded Web Server, follow these steps:
Open the 'Auxiliary Files' screen (Software Update menu > Load Auxiliary Files); the
1
'Auxiliary Files' screen is displayed (see Figure 31 on page 56).
Click the Browse button that is in the field for the type of file you want to load.
2
Navigate to the folder that contains the file you want to load.
3
Click the file and click the Open button; the name and path of the file appear in the field
4
next to the Browse button.
Click the Send File button adjacent to the field that contains the name of the file you
5
want to load. An asterisk in the screen section indicates that the file's loading takes effect
on-the-fly (e.g., Voice Prompts file).
Repeat steps 2 to 5 for each file you want to load.
6
