Embedded Web Server Login Screen
Figure 16
In the 'User Name' and 'Password' fields, enter the username (default: "Admin") and
3
password (default: "Admin"). Note that the username and password are case-sensitive.
Click OK; the 'Quick Setup' screen is accessed, shown in Figure 17 on page 33 (MGCP),
4
Figure 18 on page 35 (H.323), and Figure 19 on page 37 (SIP).

Configuring the VCX V7111 Basic Control Protocol Parameters

To configure the VCX V7111 basic control protocol parameters use the Embedded Web
Server's 'Quick Setup' screen.
For MGCP, see "Configuring Basic MGCP Parameters" on page 33.
For H.323, see "Configuring Basic H.323 Parameters" on page 34.
For SIP, see "Configuring Basic SIP Parameters" on page 36.
When you have completed the above relevant section you are ready to start using the VCX
V7111. For information on how to fully configure the VoIP gateway, see the 3Com VCX
V7111 VoIP SIP Gateways User Manual.
Once the gateway is configured correctly, back up your settings by making a copy
of the VoIP gateway configuration (ini file) and store it in a directory on your
computer. This saved file can be used to restore configuration settings at a future
time. For information on backing up and restoring the gateway's configuration see
Chapter 5: Restoring and Backing Up the VCX V7111 Configuration on page 43.
32 3Com VCX V7111 Fast Track Installation Guide
