Life Line cable (RJ-11 adaptor cable for 1 to 2). Supplied with 2FXS, 4FXS, 8FXS,
24FXS, only.
3 brackets (2 short, 1 long) and bracket-to-device screws for 19-inch rack installation
option (4FXO and 8FXO only).
2 short equal-length brackets and bracket-to-device screws for 24FXS19-inch rack
installation.
3Com VCX V7111 Fast Track Installation Guide.
Mounting the VCX V7111
3Coms' VCX V7111 can be mounted on a desktop or on a wall (only 8, 4, 2FXS), or installed
in a standard 19-inch rack.
Mounting the VCX V7111 on a Desktop
No brackets are required. Simply place the VCX V7111 on the desktop in the position you
require.
Figure 2 shows the VCX V7111 8FXS. The front panels of the VCX V7111 2FXS,
4FXS/FXO, and 8FXS/FXO are similar except for the number of channels and their
corresponding LEDs.
Desktop Mounting
Figure 2
14
3Com VCX V7111 Fast Track Installation Guide
