C 6: M
HAPTER
The VCX V7111 provides the following ways of monitoring the status of the gateway:
Monitoring the VCX V7111 front panel LEDs (see "Monitoring the VCX V7111 Front
Panel LEDs" below).
Monitoring the VCX V7111 rear panel LEDs (see VCX V7111 Rear Panel LEDs on page
46).
Monitoring the VCX V7111 channels via the Embedded Web Server (see "Monitoring the
VCX V7111 Channels" on page 46).

Monitoring the VCX V7111 Front Panel LEDs

The VCX V7111 front panel LEDs indicate the Ethernet LAN status, Data (RTP) activity and
state of the gateway ports. Table 11 describes the meaning of each state of the LEDs on the
front panel.
Definition of VCX V7111 Front Panel LED Indicators
Table 11
LED Type
Device
Ready
Status
Ethernet
LAN
Link Status
Control
Control
Link
Packet
Data
Status
Telephone
Channels
Interface
3Com VCX V7111 Fast Track Installation Guide
ONITORING THE
Color State
Green ON
Orange Blinking
Red ON
Green ON
Red ON
Toggles
Green
/ Blinking
Blank
Green Blinking
Red Blinking
Blank
Green ON
Green Blinking

VCX V7111

Definition
Device powered, self-test OK
Software loading/Initialization
Malfunction
Valid 10/100 Base-T Ethernet connection
Malfunction
MGCP:
Changes between green and off. Indicates activity,
control messages are received in real time.
H.323 / SIP:
Sending and receiving H.323 / SIP messages.
No traffic.
Transmitting packets
VCX V7111 is receiving data packets
No traffic
The phone is off-hooked (FXS); the FXO off-hooks
the line towards the PBX.
There's an incoming call, before answering
45
