Definition of VCX V7111 Front Panel LED Indicators
Table 11
LED Type

VCX V7111 Rear Panel LEDs

The LEDs on the rear panel are located within the RJ-45 socket. Table 12 describes the
meaning of each state of the LEDs on the rear panel.
Definition of VCX V7111 Rear Panel LED Indicators
Table 12
Label Type
Ethernet
ETH-1
Status

Monitoring the VCX V7111 Channels

To monitor the status of the channels:
Open the Channel Status screen (Status & Diagnostics menu > Channel Status); the
Channel Status screen is displayed.
VCX V7111 FXS Channel Status Screen
Figure 23
The color of each channel shows the call status of that channel.
Inactive indicates this channel is currently on-hook.
Handset Off-Hook indicates this channel is off-hook but there is no active RTP session.
46
Color State
Red ON
Blank
Color State Definition
Yellow ON Ethernet port receiving data
Red ON Collision
Definition
Line malfunction
Normal on-hook position
3Com VCX V7111 Fast Track Installation Guide
