NOtE!
please also refer to the chapter „Submenu" for selectable display options. Via the Folder Search But-
tons -6- it is possible to navigate directly through the generated folders. all further player functions are
equal to the normal CD/Mp3 mode.
WOrtH KNOWING!
please also refer to the chapter „uSB audio Link" in order to connect two rMp-3 players and to access
one uSB MIDI source.

MIDI MODE

By holding the Source Select Button -48- for a longer period of time you will change to MIDI Mode. The
Source Select Button glows purple, „DeckA CH1" appears on the display. The remark „DeckA CH1" means
that all elements are sending on MIDI channel 1. By pushing the Reverse/Deck Switch Button you can
switch from channel 1 (Deck A) to channel 4 (Deck D). This way an easy handling of up to 4 virtual players
becomes possible. Further information can be found in the chapter „Submenu" and in the TRAKTOR PRO
mapping.
NOtE!
regularly check our website www.reloopdj.com for possible firmware updates and new mappings.
Each element of the player sends MIDI commands. Please also refer to the MIDI map included in this ma-
nual.
a) reverse/Deck Switch Button
By pushing the Reverse/Deck Switch Button -10- it is possible to comfortably switch between 4 MIDI chan-
nels. The current channel and as the case may be the virtual deck drive will appear on the display. If, for
example, you would like to control 4 virtual decks with one RMP-3 you can switch between the virtual
decks via the Deck Switch Button. The channel presets can be adjusted in the submenu (also see chapter
Submenu).
b) Shift Button
By holding the Shift Button -46- a second function of any element can be called up. This way the number of
control elements will be doubled. Please also refer to the included MIDI Map in this manual.
c) Jog Wheel
The large, touch-sensitive Jog Wheel -18- can send MIDI commands in four different modes:
• normal mode
Sends data when turning/touching the Jog Wheel.
• X-parameter
With activated X-Parameter Button -25- the Jog Wheel sends different data.
• y-parameter
With activated Y-Parameter Button -26- the Jog Wheel sends different data.
• Shift Mode
When holding the Shift button -46- the Jog Wheel also sends different data.
NOtE!
two different MIDI sampling rates can be selected for the Jog Wheel.
• High resolution = 1.024
• Low resolution = 512
For further information please refer to the chapter „Submenu".
d) MIDI Command Editing
Generally speaking each element is freely editable.
For further information please refer to the chapter „Submenu".
e) traKtOr prO Mapping
The RMP-3 is implemented as MIDI controller in the most current TRAKTOR PRO versions and it can
be selected as controller in the defaults. The functions are assigned as follows:
41
