P R O 4 8
WAT E R L I N E
pproximately 0,9 m of
connected to the ice maker with a preassem-
bled
This tubing is located under the unit.
The water line fitting connection kit,
provided with the unit, contains a
compression sleeve and a
nut for connection to the household water
line. Place the compression nut and sleeve
on the water line and fasten to the connec-
tion at the end of the tubing under the unit.
Do not over tighten. Check all water line
fittings for leaks. Make sure that the drain
pan can be installed or removed without any
water line interference.
IMPORT NT NOTE: Be sure to purge the
water line prior to final connection to the
unit. This will remove any debris that may
be present in the tubing from installing the
new water line.
IMPORT NT NOTE: Let your customer
know that the ice maker will not produce ice
immediately, and that the first bucket of ice
produced should be discarded. llow 48
hours of ice production, before discarding
the first bucket of ice.
16
I N S TA L L AT I O N I N S T R U C T I O N S
C O N N E C T I O N
1
/
" plastic tubing is
4
1
/
" compression connection at the end.
4
1
/
" compression
4
L E V E L I N G
Once the unit is in position, extend the front
leveling legs down by turning the legs
counterclockwise and adjust the height. The
rear height adjustment can be made from
the front of the base. Use a
adjust the rear rollers. Turn the
1
/
"
4
clockwise to raise the unit or counterclock-
wise to lower it.
When the unit is leveled properly, or squared
off, door and/or drawer adjustments are less
likely to be necessary. Refer to the illustra-
tion below for location of the rear roller base
adjustment.
IMPORT NT NOTE: Be sure to reference
leveling of the unit to the floor and not to
surrounding cabinetry. This could affect the
operation of the unit, such as doors not
closing properly.
I N S TA L L T H E
To install, screw the kickplate to brackets
attached to the inside surface of each roller
base.
T H E U N I T
5
/
" socket to
16
5
/
" hex bolt
16
K I C K P L AT E
Rear roller base adjustment
