TROUBLESHOOTING GUIDES
This section of the manual contains:
• The Error Code Table and Error Code Troubleshooting Guide.
• The General Troubleshooting Guide, which covers all problems that an ICB700 Series Tall unit may experience.
• The Membrane Switch/Ribbon Cable Test Procedures, used to determine if a control panel assembly is defective.
• The Door Hinge Test Procedures and Corrections explain how to test and correct door closing problems.
HOW TO USE THE ERROR CODE TROUBLESHOOTING GUIDE
Error Codes are logged for thermistor errors, and/or defrost system errors. If Error Codes are logged, they will
appear when Diagnostic Mode is initiated.
NOTE:
If Error Codes appear with a flashing "SERVICE" indicator prior to initiating Diagnostic Mode, the unit expe-
rienced excessive compressor run condition that may or may not be associated with the Error Codes displayed.
To initiate Diagnostic Mode, press and hold either COLDER key, then press the POWER key, then release both
keys. Now, check to see if Error Codes are present, being sure to toggle through all error and temperature readings
by pressing either COLDER key or either WARMER key. (See Error Code Table Below)
If Error Codes appear, follow the Error Code Troubleshooting Guide on the following page. The left column of the
troubleshooting guide lists the error codes. The information in the right column explains what tests to perform and/or
what action to take to correct the error.
NOTE:
If error codes are observed in diagnostic mode, a non-flashing SERVICE indicator will appear on the LCD
when Diagnostic Mode ends indicating error codes are still stored. Error Codes must be manually cleared from the
electronic control memory. To clear the non-flashing SERVICE indicator and the error codes, the problem must be
corrected and the unit must be ON. Then, press and hold the ALARM key for fifteen (15) seconds. The control will
emit a short "beep" when the SERVICE indicator and error codes are cleared.
CODE INDICATION
05
Refrig. cabinet thermistor read open or shorted for 10+ seconds, or repeatedly read erratic temp's
06
Refrig. evaporator thermistor read open or shorted for 10+ seconds, or repeatedly read erratic temp's
07
Freezer cabinet thermistor read open or shorted for 10+ seconds, or repeatedly read erratic temp's
08
Freezer evaporator thermistor read open or shorted for 10+ seconds, or repeatedly read erratic temp's
20
Defrost under-heat with no voltage feedback through Gray/White wire at defrost start
21
Defrost overheat
22
No voltage feedback through Gray/White wire at defrost start
23
Defrost overheat with no voltage feedback through Gray/White wire at defrost start
24
Defrost Under-heat
30
Excessive Icemaker Water Valve Solenoid Activation (Exceeded 15 Seconds)
40
Excessive Freezer Compressor Run
50
Excessive Refrigerator Compressor Run
7005836 - Revision A - January, 2009
International Integrated
International Integrated
Error Code Table
8-2
Series
Series
(ICB700 T
all)
(ICB700 T
all)
