4.16 Rotating the Coordinate Axes

This function allows the cutting/plotting origin and coordinate axes to be rotated as shown below.
C L E A R B U F F E R
F E E D & C U T
B L A D E W A R E S E T U P
P E N U P / D O W N
C U T L I N E P A T .
T A N G E N T I A L
I N I T . B
P E N U P S P E E D
I N I T I A L F E E D
A U T O P R E F E E D
A D V A N C E D F U N C .
S E T U P M E N U
T E S T
4-20
New origin
Y
When axis-coordinate
X
rotation is "on"
Y
X
Origin
(1) Press the (PAUSE) key to switch to PAUSE mode.
(2) Press the (NEXT) or
A D V A N C E D F U N C .
(3) Press the (ENTER) key, and then press the
until the following menu is displayed.
R O T A T E
(4) Press the (ENTER) key to display the coordinate-axis rotation-setting menu.
R O T A T E
Press the or
(ENTER) key to confirm. To cancel the selection, press the
(PREV.) key.
(5) Press the (PAUSE) key to cancel PAUSE mode.
CHECKPOINT
This setting is retained in the memory even when the power is turned off.
When axiscoordinate
rotation is "off"
(PREV.) key until the following menu is displayed.
O F F
key to select "ON" or "OFF," and then press the
(NEXT) or
(PREV.) key
(NEXT) or
