Vehicle care and maintenance
No. Symbol
32
33 —
34 —
35 —
*: Fusible link
Some fuses may not be installed on your vehicle, depend-
ing on the vehicle model or specifications.
The table above shows the main equipment corresponding
to each fuse.
There are no 7.5 A, 25 A or 30 A spare fuses. If a fuse of one of
these capacities blows, replace it temporarily by borrowing one
of the fuses indicated below.
7.5 A: 10 A spare fuse
25 A: 20 A spare fuse
30 A: 30 A audio amplifier fuse
Replace the borrowed fuse with a fuse that has the correct
capacity as soon as possible.
7
7-48
Electrical system Capacity
Diesel 30 A
Spare fuse 10 A
Spare fuse 15 A
Spare fuse 20 A

Identification of fuse

Capacity
7.5 A
10 A
15 A
20 A
25 A
30 A Green (fuse type) /Pink (fusible link type)
40 A Green (fusible link type)
Color
Brown
Red
Blue
Yellow
Natural (white)
