USB Ports

Description:Two USB 2.0 ports (USB 1, 2).
Functionality:Connects with a USB flash drive device, which can be used for loading software
upgrades to the SyncServer, as well as for backing up and restoring the SyncServer con-
figuration.
Connection:Requires a compatible USB memory device, such as a SanDisk cruzer micro USB
device (recommended). Not all USB flash drives are compatible with the SyncServer's USB
ports.
Also see:Keypad/Display Interface (on page 73), SYSTEM - Upgrade (on page 53),
WIZARDS - Upgrade (on page 71), WIZARDS - Backup (on page 70), WIZARDS - Restore
(on page 71).

VAC Power Supply

Description:Universal type VAC Power supply
Connector:IEC 320
Input Voltage Range:90-264 VAC
Input Frequency Range:47-63 Hz
Max. Power:
With Rubidium Osc
Without Rubidium Osc 25 watts

VDC Power Supply

This topic applies to the 48 VDC Operation Model only.
Description:VDC Power Supply
Connector:Two three-position screw terminal blocks
Input Voltage Range:40-60 VDC, 50 watts maximum, 1.5 amps
Isolation, Ground:Input is fully floating. Either input polarity may be strapped to chassis ground
at the input terminal block.
Isolation:Input to output 1,000 VAC minimum

Timing Holdover

Temperature Compensated Crystal Oscillator (TCXO)
997-01520-02 Rev.
Initial Power On Continuous
45 watts 35 watts
21 watts
G2..........................................................................
