Position: The latitude and longitude of the GPS antenna in degrees, minutes, and fractional
seconds. Referenced to WGS-84.
Altitude: The altitude of the antenna in meters. Referenced to WGS-84.
Satellites: The list of GPS satellites visible to the receiver:
Sat Number: The GPS satellite's Satellite Vehicle (SV) number, a unique identification
n
number
Signal: The relative strength of the GPS signal (dBW = decibels relative to 1 Watt).
n
Status: "Current" means that the receiver is using the GPS signal in its timing solution.
n
"Tracked" means the receiver is tracking the signal, but isn't using it in the timing solution.
See GPS (on page 173) default settings

STATUS- NTP

This page displays the status of the NTP Server.
Values are displayed for:
system peer
n
system peer mode
n
leap indicator
n
stratum
n
precision
n
root distance
n
root dispersion
n
reference ID
n
reference time
n
system flags
n
jitter
n
stability
n
broadcast delay
n
authdelay
n
See default settings:
NTP (on page 171)
n
NTP Override Behaviour (on page 172)
n

STATUS- Alarms

Current Major or Minor Alarms
Alarms with Severity set to:
Major are displayed in red text.
n
Minor are displayed in orange text.
n
Notify are not displayed.
n
