Scanner Part - Brother DCP-7080 Service Manual

2.1.2 Scanner part

ADF cover ASSY
Second side white bar
Document feed
roller ASSY 1
First side document
scanning position
actuator
First side white bar
First side document scanning
position sensor
First side CIS unit
Document separate roller
Document detection actuator
Document feed
Document pick-up roller
ADF
roller ASSY 2
separation
pad
Second side
Second side
document scanning
CIS unit
position sensor
Second side document scanning
position actuator
ADF cover actuator
Document guide
Document ejection roller ASSY
Document detection sensor
Fig. 2-3
2-5
ADF document support
Document cover ADF document output support flap
Scanner glass
