AXIOMTEK SHB101 Series User Manual page 95

22 a_PETn12 GND
23 GND a_PERp12
24 GND a_PERn12
25 a_PETp13 GND
26 a_PETn13 GND
27 GND a_PERp13
28 GND a_PERn13
29 a_PETp14 GND
30 a_PETn14 GND
31 GND a_PERp14
32 GND a_PERn14
33 a_PETp15 GND
34 a_PETn15 GND
35 GND a_PERp15
36 GND a_PERn15
37 N.C GND
38 N.C N.C
39 GND GND
40 GND GND
41 GND GND
42 GND GND
43 GND GND
44 +12V +12V
45 +12V +12V
46 +12V +12V
47 +12V +12V
48 +12V +12V
49 +12V +12V
Note Please contact your vendor to get the backplane
design guide if it's required. The backplane design
guide is NDA required.
PICMG v1.3 Interface Definition
SHB101 LGA775 Full-Size SBC User's Manual
22 C/BE3#
23 AD23
24 GND
25 AD21
26 AD19
27 +5V
28 AD17
29 C/BE2#
30 PCI_PRST#
31 IRDY#
32 DEVSEL#
33 LOCK#
34 PERR#
35 GND
36 PAR
37 N.C
38 GND
39 AD15
40 AD13
41 GND
42 AD11
43 AD08
44 GND
45 AD07
46 AD04
47 GND
48 AD03
49 AD00
AD24
+3.3V
AD22
AD20
N.C
AD18
AD16
GND
FRAME#
TRDY#
+5V
STOP#
GND
C/BE1#
AD14
GND
AD12
AD10
GND
AD09
C/BE0#
GND
AD06
AD05
GND
AD02
AD01
GND
89
