AXIOMTEK SHB101 Series User Manual page 93

31 GND REFCLK1+
32 RSVD REFCLK1-
33 REFCLK2+ GND
34 REFCLK2- GND
35 GND REFCLK3+
36 RSVD REFCLK3-
37 REFCLK4+ GND
38 REFCLK4- GND
39 GND N.C
40 RSVD N.C
41 N.C GND
42 N.C GND
43 GND N.C
44 GND N.C
45 a_PETp0 GND
46 a_PETn0 GND
47 GND a_PERp0
48 GND a_PERn0
49 a_PETp1 GND
50 a_PETn1 GND
51 GND a_PERp1
52 GND a_PERn1
53 a_PETp2 GND
54 a_PETn2 GND
55 GND a_PERp2
56 GND a_PERn2
57 a_PETp3 GND
58 a_PETn3 GND
59 GND a_PERp3
60 GND a_PERn3
61 a_PETp4 GND
62 a_PETn4 GND
63 GND a_PERp4
64 GND a_PERn4
65 a_PETp5 GND
66 a_PETn5 GND
67 GND a_PERp5
68 GND a_PERn5
PICMG v1.3 Interface Definition
SHB101 LGA775 Full-Size SBC User's Manual
31 N.C
32 N.C
33 N.C
34 N.C
35 N.C
36 GND
37 GND
38 N.C
39 N.C
40 GND
41 GND
42 +3.3V
43 +3.3V
44 +3.3V
45 +3.3V
46 +3.3V
47 +3.3V
48 +3.3V
49 +3.3V
50 +3.3V
51 GND
52 GND
53 GND
54 GND
55 GND
56 GND
57 GND
58 GND
59 +5V
60 +5V
61 +5V
62 +5V
63 GND
64 GND
65 GND
66 GND
67 GND
68 GND
Mechanical Key
N.C
N.C
N.C
GND
GND
N.C
N.C
GND
GND
N.C
N.C
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
GND
GND
GND
GND
GND
GND
GND
GND
+5V
+5V
+5V
+5V
GND
GND
GND
GND
GND
GND
87
