SHB101 LGA775 Full-Size SBC User's Manual

2.4.16 USB Port Connector (USB3/USB4)

The 4-pin standard Universal Serial Bus (USB) port connector on the
board is for the installation of peripherals supporting the USB interface.
Pin
1 USB POWER
2
3
4

2.4.17 DB15 CRT Connector (VGA1)

VGA1 is a DB15 connector commonly used for the CRT Monitor.
Pin Signal
1 Red
4 NC
7 GND
10 GND
Horizontal Sync
13
VGA1
18
Signal
USB -
USB +
GND
Pin Signal
2 Green
5 GND
8 GND
11 NC
14 Vertical Sync
USB3/4
Pin Signal
3 Blue
6 DETECT
9 VCC
12 DDC DATA
15 DDC CLK
Jumpers and Connectors
