Configuration Manual
Ascom i62 VoWiFi Handset
1.
Introduction
This document is a guide for installing, configuring and maintaining functionality of the
Ascom i62 VoWiFi Handsets.
The Ascom Voice over Wireless Fidelity (VoWiFi) system provides wireless IP-telephony,
messaging and alarm functions to enterprise LANs. Using third-party WLAN products as well
as in-house developed hardware and software, the system enables data and voice
transmission together with seamless roaming.
Figure 1.
VoIP Gateway
This document is intended as a guide when installing the Ascom i62 VoWiFi Handset in a
VoWiFi system. The document describes the settings needed to make the handset function
in a VoWiFi system and is relevant to the following personnel:
• System Administrator
• Service Technician
First configuration is done using the Portable Device Manager (PDM). In small systems
where it is possible to collect all handsets to update settings, daily maintenance is also done
by using the PDM. In larger installations, the Device Manager in the Messaging and Services
application (IMS3) makes it possible to administrate the handsets centrally via a web
interface without the need to collect the handsets.
The handset behavior can be customized to suite each user profile.
It is recommended that the reader has basic knowledge of the Ascom VoWiFi system and
basic knowledge of handset registration in the PBX.
20 June 2012 / Ver. E
1. Introduction
Ascom VoWiFi System
PDM
Device Manager
in IMS3
PBX
AP
AP
IP-PBX
VoWiFi Handset
TD 92675EN
Switch to IP Backbone/LAN/Internet
1
