Configuration Manual
Ascom i62 VoWiFi Handset
3
The following settings for the profile can configured:
• Profile name
• Internal/External/Callback ring signal
• Ring volume
• Vibrator
• Key sound
• Message alert signal
• Answering settings
• Diversion settings
Diversions
Calls can be diverted to other phone numbers, for example when busy.
1
In the applicable profile, select Diversions.
2
Activate a diversion by selecting "Enable" in the applicable diversion drop-down lists.
The following diversions are possible:
• Activate diversions for all calls
• Activate diversions on user busy
• Activate no answer diversions
3
Enter the diversion number in the applicable diversion number text field.
4
If the handset is configured to access the PBX via SIP protocol, the handset can be
configured to manage the diversion locally instead of using the PBX. Requires that
the handset is within the coverage area and is switched on.
Select VoIP > SIP. In the Call forward locally drop-down list, select "Enable".
6.5.7
Hide Missed Call Window
A missed call is by default indicated by a Missed call window. It is possible to hide this
window, for example, if both a handset and a mobile is used. If the user answers the call
using the mobile, the Missed call window will not be displayed in the handset.
1
Select Device > Call.
2
In the Show missed calls popup drop-down list, select "No" to hide the Missed call
window.
6.5.8
Battery Warning
1
Select Device > Settings
2
In the Battery warning drop-down list, select one of the following:
• Sound repeatedly
• Sound once
• Sound off
6.5.9
Shared Phone
1. Applicable to Messenger and Protector only.
20 June 2012 / Ver. E
6. Handset Configuration
1
TD 92675EN
39
