Configuration Manual
Ascom i62 VoWiFi Handset
4.4.4

Save Handset Configuration as a Template

It is possible to save all settings of a handset as template. Note that this does not include
contacts, certificates and other personal data. The template will only contain configuration
data.
This template can be used as a backup if you want to restore the configuration of the
handset at a later stage or as a template that can be applied to a number of handsets.
1 Open PDM or the Device Manager in the IMS3.
2 In the Numbers tab, select the handset you want to save as a template.
3 Make a right-click and select "Use as a template...". Enter a descriptive name for the
template.
4 The Edit template window is opened. By default, all parameters are selected and are
saved when clicking "OK".
If one or more parameters should be excluded, remove them by clearing the check
box next to the parameter.
Some parameters are user specific. If it is decided to apply this type of template to
several handsets, it is recommended to exclude the following parameters:
• User display text - A text string displayed in idle mode. The parameter is located
directly under "Settings".
• Phone lock PIN code - The security code used to unlock the keypad. The parameter
is located under Settings > Locks.
• Endpoint ID - The identity/name of the user registered in the PBX. The parameter
is located under VoIP > General.
5 Click "OK".
4.4.5

Synchronizing a Handset with PDM

After installing and saving a handset, it will be synchronized each time it is connected to the
PDM. The synchronization transfers parameter changes between the handset and the PDM
and vice versa as follows:
• If a parameter has been changed in the handset, it will be transferred to the PDM/IMS3.
• If a parameter has been changed in the PDM/IMS3 while the handset was disconnected,
it will be transferred to the handset.
If the same parameter has been changed in both the PDM/IMS3 and the handset, the value
in PDM/IMS3 will be transferred to the handset.
4.4.6

Configure Handset without Saving It in PDM

It is possible to configure a handset without saving it in the PDM. An unsaved handset do
not have the symbol
synchronized and saved in the PDM later on. However, it is recommended to save the
handset in PDM if backup is needed. For example when a handset needs to be replaced.
1 Put the handset in the Desktop Programmer (DP1) cradle
2 Open PDM.
3 In the Numbers tab, select the unsaved handset you want to configure.
4 Select Number > Edit parameters.
5 The Edit parameters window is opened. Edit the parameters of the handset and click
"OK".
6 Remove the handset from the Desktop Programmer (DP1) cradle. The handset is no
longer visible in the PDM and the settings are only saved in the handset.
20 June 2012 / Ver. E
4. Installation of VoWiFi
in the Saved column. The settings in the handset can be
TD 92675EN
15
