Installation Without Central Device Management (Ims3) - ASCOM i62 Configuration Manual

Configuration Manual
Ascom i62 VoWiFi Handset
Settings that were stored for the handset in the Device Manager in IMS3 will now be
downloaded to the handset. This can, for example, be unique soft- or hot keys that have
been prepared earlier. When the settings have been downloaded to the handset, it might be
restarted depending on the parameter changes.
7 Repeat step 3 – 6 for all handsets.
4.2

Installation without Central Device Management (IMS3)

In a small VoWiFi system, the administration can be handled using only the PDM.
The synchronization is in this case not handled automatically by the system when a
handset's parameters are changed in the PDM. When the parameters have been changed in
PDM, each handset must be placed in the Desktop Programmer (DP1) cradle connected to
the administrator's computer in order to synchronize the parameters with the handset.
1 Open the PDM.
2 In the Numbers tab, click "New". The New numbers window is opened.
3 In the Device Type and Parameter version drop-down lists, select the matching device
type and the parameter version for the handset to be use, respectively.
4 In the Prefix field, enter the numbers' prefix (if needed).
5 Create a range of numbers by selecting the "Range" option. Enter the start call
number and the end call number in the fields, respectively.
6 Click "OK".
7 Create a network settings template (see
the following network parameters:
• Network settings
8 Create another template (see
handset settings applicable to all handsets (exclude the network parameters and
used security settings). Example of parameters settings:
• VoIP settings
• Software TFTP IP address (if any) (located under Device > General)
• Syslog settings
In addition, settings for hiding menu items in the display, certain level of ring signal
and vibrators etc. can also be configured.
9 Apply the network settings template to the handset, see
Handset with a Number
10 Apply the common settings template to the handset, see
Handset with a Number
11 Put the handset in the Desktop Programmer (DP1) cradle.
12 In the Device Wizard window, select "Associate with number" and press "OK".
13 Select the handset to associate with. Press "OK".
The number and parameter settings saved in the PDM will now be synchronized with the
handset. In addition, the handset's Device ID will also be synchronized with the number in
the PDM.
If certificates must be used to access a VoWiFi system, also perform the steps 14 - 19.
1. All required system settings for the WLAN. For example SSID and Security mode.
2. VoIP protocol, Gatekeeper IP address or SIP proxy IP address used to access the PBX.
3. The parameter "Syslog" must be enabled in order to set the "Syslog IP address".
20 June 2012 / Ver. E
4. Installation of VoWiFi
1
(located under Network > Network A, B, C, or D)
4.4.1 Create a template
2
(located under VoIP)
3
(if any) (located under Device > General)
on page 14.
on page 14.
4.4.1 Create a template on page 14) with
on page 14) with the common
4.4.2 Apply a Template to a
4.4.2 Apply a Template to a
TD 92675EN
12
