Configuration Manual
Ascom i62 VoWiFi Handset
6.9.8
Message Centre Number
Specifies the number to the server for Message Waiting Indication (MWI) if included in the
system.
1
Select Device > Message centre.
2
In the Message Centre number field, enter the number to the server.
3
In the Voice mail call clears MWI drop-down list, select "Enable" to clear MWI in the
message centre when calling the defined voice mail number.
6.9.9
Max number of Call Completions
Specifies the maximum number of call back requests the handset can handle.
1
Select Device > Call.
2
In the Max number of call completions drop-down list, enter number of calls
6.9.10 Dial Pause Time
By adding a "P" to a phone number, a pause is added and will be activated when dialing. For
how long is defined here.
1
Select Device > Call.
2
In the Dial pause time field, enter a pause time between 1 - 3 seconds.
6.9.11 Direct off Hook from Charger
The handset will automatically answer a call (that is; quick answer) when removed from the
charger.
1
Select Device > General.
2
In the Direct off hook from charger drop-down list, select "Enable".
6.9.12 Replace Call Rejected with User Busy
Is used if the system does not support call rejected.
1
Select Device > General.
2
In the Replace Call Rejected with User Busy drop-down list, select "Enable".
6.9.13 Busy on 1 / Disable call waiting
The default behavior is to indicate "call waiting" to the user. It is possible to change this
behavior so that the next incoming call is rejected and a busy indication sent back to the SIP
proxy.
1
Select Device > Call.
2
In the Busy on 1 / Disable call waiting drop-down list, select "Yes".
6.9.14 Calling Line Restriction
The handset may be configured to hide the calling number and name to the called party.
1
Select Device > Call.
2
In the CLIR (Calling Line Information Restriction) drop-down list, select "On".
20 June 2012 / Ver. E
6. Handset Configuration
TD 92675EN
53
