Configuration Manual
Ascom i62 VoWiFi Handset
1 Open a web browser and enter the address to the IMS3.
2 Click "Device Manager". You might be prompted to log on the Device Manager.
3 Select the Templates tab and click "New". The New template window is opened.
4 In the Device type and Parameter version drop-down lists, select the corresponding
device type and parameter version to use, respectively.
5 In the Name field, enter a descriptive name of the template.
6 Click "OK".
7 Set the following network parameters:
• Network settings
• VoIP settings
• Syslog settings
• Unite settings
8 Click "OK" to save the template.
Tip: See Appendix A
4.1.2

Create a Common Template in the IMS3

Create another template with the common handset settings applicable to all handsets
(exclude the parameters and security settings configured in the Network template). This
template contains for example, hidden menu items in the display, certain level of ring signal
and vibrators.
NOTE: Only select the parameters that are changed, if all parameters are selected the system
performance decreases.
1 Open a web browser and enter the address to the IMS3.
2 Click "Device Manager".
3 Select the Templates tab and click "New".
4 In the Device Type and Parameter version drop-down lists, select the corresponding
device type and parameter version to use, respectively.
5 In the Name field, enter a descriptive name of the template.
6 Set the specific parameters. See section
page 13 for more information.
4.1.3

Create Numbers in the IMS3

Create a range of Numbers and apply the templates previously created in the IMS3.
IMPORTANT: Do not add numbers already used because these handsets already exist in the
NOTE: The parameter version of the template must be equal to or less than the selected
parameter version.
1 Open a web browser and enter the address to the IMS3.
1. All required system settings for the WLAN. For example SSID and Security mode.
2. For example VoIP protocol, Gatekeeper IP address or SIP proxy IP address used to access the PBX.
3. The parameter "Syslog" must be enabled in order to set the "Syslog IP address".
4. IP address and password (if any) to the IMS3.
20 June 2012 / Ver. E
4. Installation of VoWiFi
1
(located under Network > Network A, B, C, or D)
2
(located under VoIP)
3
(if any) (located under Device > General)
4
(located under Device > Unite)
for tip on how to work with templates when using both PDM and IMS3.
system although not saved in the Device Manager in IMS3. The Device Manager
will overwrite the existing parameters in the handset.
4.4 Configure a Handset with a Template
TD 92675EN
on
10
