4.6 Field Definition — Human Readable Fields
Field definition statements to be sent after "STX L" SYSTEM LEVEL
command. LABEL FORMATTING mode terminated by "E" or "X"
LABEL FORMATTING command.
Field Record for Label Input Mode
Human Readable Fields:
CHAR # DESCRIPTION
1 Flag for rotation.
1 = 0 deg.
2 = 90 deg.
3 = 180 deg.
4 = 270 deg.
2 Font selected.
Any valid font character.
Bar codes automatically select bar code field format.
3 Horizontal multiplier.
1 = X1, 2 = X2, 4 = X4.
4 Vertical multiplier.
1 = X1, 2 = X2, 4 = X4, 8 = X8.
5, 6, 7 Always 0 0 0. Must be 3 digits.
8, 9, 10, 11 Row address. Must be 4 digits. ( 0.01"/step)
0000-9999
12, 13, 14, 15 Column address. Must be 4 digits. ( 0.01"/step) 0000-
0447
16, . . . String data.
ASCII printable data for font selected.
Terminate with a <CR>.
^B Switch to string input commands:
Sn Select stored string from global table.
Strings stored by the "G" label formatting command
n = String location. A-P.
________________________________________________________
__
Using the Printer Page - 53
