BAR CODES With Interpretation Line

(UPPERCASE)
Ratio Based Barcodes
203 DPI Printer (actual dpi - 203)
Ratio
(i.e. 2:1, 3:1, 5) 2:1
Narrow Bar
Name 0.005
A 30F9 15.62
D 120F5 14.50
H HIBC 15.62
I CODABAR 14.50
J 16.92
120F5 W/BARS
K PLESSEY 20.30
L UPC CASE 14.50
152 DPI Printer (actual dpi - 153.8)
2:1
Narrow Bar
Name 0.006
A 30F9 11.83
D 120F5 10.99
H HIBC 11.83
I CODABAR 10.99
J 12.82
120F5 W/BARS
K PLESSEY 15.38
L UPC CASE 10.99
Page - D2
5:2 3:1 2:1
0.005 0.005 0.010
7.00 12.69 7.81
6.34 11.28 7.25
7.00 12.69 7.81
6.34 11.28 7.25
7.25 12.69 8.46
9.23 16.92 10.15
6.34 11.28 7.25
5:2 3:1 2:1
0.006 0.006 0.0130
5.31 9.62 5.92
4.81 8.55 5.49
5.31 9.62 5.92
4.81 8.55 5.49
5.49 9.62 6.41
6.99 12.82 7.69
4.81 8.55 5.49
5:2 3:1
0.010 0.010
3.50 6.34
3.17 5.64
3.5 6.34
3.17 5.64
3.63 6.34
4.61 8.46
3.17 5.64
5:2 3:1
0.0130 0.0130
2.65 4.81
2.40 4.27
2.65 4.81
2.40 4.27
2.75 4.81
3.50 6.41
2.40 4.27
Appendix D
