5.2.1 ALT Keys

Several very important and powerful Printer settings are called up
and/or controlled by the ALT key. To use the ALT functions, press and
hold the ALT key as you press another key. The ALT functions are:
ALT-P
While in the far left position (ROT) of the CREATE/MODIFY LABEL
screen or the SAMPLE? position of the PRINT LABEL screen, press
ALT-P to bring up the PRINT PARAMETERS window. It looks like
this:
PRINTER ADJUSTMENTS
HEAT FACTOR:
PRINT SPEED:
SLEW SPEED:
DOT PATTERN(5 mil):
FORMAT W/Z:
ROW OFFSET:
COLUMN OFFSET:
COUNT BY:
MAX LABEL WIDTH:
MAX LABEL LENGTH:
CONTINUOUS FORMS:
Print parameters include row and column offsets, label edge offset, pixel
(dot) size, print speed, slew (feed) rate, heat setting, and the type of print
mode desired ("WAIT" OR "ZIP").
Use the arrow keys to move from one position to the next. Key in any
values that need to be changed. Press the ESC key to exit the window.
________________________________________________________
__
Page - 84
10
E
G
2x2
Z
00.00
00.00
01
04.47
12.00
NO
Using the Printer's Internal Labeling Software
