3.4 Explanation of the Self Test Label

Below is an illustration of an actual Configuration Label. The label
contains information of the Printer's current setup settings, as well as the
RAM and ROM checksums, and other important information.
PROGRAM VERSION:
SYSTEM ROM CHECKSUM:
FONT ROM CHECKSUM:
TOTAL ROM SUM:
SYSTEM RAM-U15 CHECKS GOOD
SYSTEM RAM-U16 CHECKS GOOD
SYSTEM RAM-U17 CHECKS GOOD
SERIAL PORT BAUD RATE IS 9600
TRANSFER SWITCH IS ON
SETUP SWITCH 1
OFF OFF OFF OFF OFF OFF OFF OFF
ANALOG INPUT VALUES:
PAPER: 236 EDGE: 184
Figure 3-6 Configuration Label
The following is an explanation of the Configuration Label in
Figure 3-6.
PROGRAM VERSION: PROGRAM VERSION:
This line contains the Printers firmware version level.
________________________________________________________
__
Page - 28
02.4 10/22/90
9D IS GOOD
A8 IS GOOD
45 IS GOOD
2 3 4 5 6
TEMP 064
02.4 02.4 10/22/90 10/22/90
7 8
VOLT: 228
Setup and Self Test
