Interface Cable Applications; Pin Connections - Datamax Prodigy Operator's Manual

Appendix C

Interface Cable Applications

Part Description
Number
556000 Printer to CRT Terminal (DB25P) RS-232
556001 Printer to PC 9 Pin (DB9S) RS-232
556002 Printer to PC 25 Pin (DB25S) RS-232
899516 Printer to PC Parallel Port (DB25P)

Pin Connections

All unlisted pins are not connected.
________________________________________________________
__
Appendix C
Pin Description
1 CHASSIS
2 TXD (RS-232)
3 RXD (RS-232)
4 RTS (4.7k ohm to +5VDC)
5 CTS (input)
7 LOGIC GROUND
20 BUSY (output)
9 TXD +
10 TXD -
18 RXD +
19 RXD -
Page C-1
