Null Modem Cable

HOST
NOTE: Cable is used for typical connection to other DCE
equipment with XON/XOFF flow control.

Straight Cable (MM)

HOST
1
RXD 2
TXD 3
7
4
5
DB25P
NOTE: Cable is used for typical connection to other DCE
equipment with XON/XOFF flow control.
________________________________________________________
__
Page C-2
Printer
Printer
SHIELD
1
2 TXD
3 RXD
GROUND
DB25P
Appendix C
