CanyCom CG431 Operator's Manual page 32

（Irrust indicates Hay Collector Model）
5116M-0402-101E
Implement Lift Switch(Up)
5116M-0402-110E
Parking Brake Switch
Implement Aux. Transmission Parking Brake
Direction Switch
HI
Drive
Normal
LO
Reverse
5116M-0402-010E
Forward
Control Stick
Backward
5116M-0402-120E
Operation
Throttle Lever
Main Switch
Imp
Tra
Cen
Start
1. Parking Brake
2. Imprement Switch
STOP
3. Safety Switch "ON"
4. Start Engine
3. Move throttle lever toward [
position to increase engine speed.
4. Press implement lift switch [UP] to lift
implement off the ground.
5. Turn parking brake switch to [RUN].
NOTE
• If parking brake switch is in [
position, machine does not move even
when control stick is operated.
Moving Forward/Backward
6. Move control stick gradually forward to move
machine forward, or move it backward to
travel backward. The angle of control stick
controls the machine speed.
-23-
4
(fast)]
(parking)]
