Front Flail Brushcutter
CG431 Tractor
Operator's Manual
Read this manual completely before operating or maintaining this machine.
Failure to follow safety precautions could result in serious injury or death.
Keep this manual for future reference by you and by all those who operate
and maintain this machine.
CHIKUSUI CANYCOM, INC.
90-1 Fukumasu, Yoshii-machi,
Ukiha-shi, Fukuoka, Japan 839-1396
Tel.+81-(0)943-75-2195 Fax.+81-(0)943-75-4396
5116 5106 000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CG431 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CanyCom CG431

Summary of Contents for CanyCom CG431

  • Page 1 Front Flail Brushcutter CG431 Tractor Operator's Manual Read this manual completely before operating or maintaining this machine. Failure to follow safety precautions could result in serious injury or death. Keep this manual for future reference by you and by all those who operate and maintain this machine.
  • Page 2 CHIKUSUI CANYCOM, INC. http://www.canycom.co.jp/ Sales Headquarters TEL +81-(0)943-75-2195 FAX +81-(0)943-75-4396 ■ Authorized Dealer All rights reserved. Unauthorized use or reproduction of this material is prohibited.
  • Page 3 Notice to Users and Maintenance Personnel Thank you for purchasing this machine. This manual provides information needed for safe and effective use and maintenace of this machine to those who operate or maintain the machine. Make sure to read and understand the manual thoroughly before operating or servicing the machine.
  • Page 4 Notice to Owner • Be sure that everyone who uses this machine, including those who rent or lease this machine, receives a copy of this Operator's Manual and understands the importance of reading and following the information in this manual. Warning Terms Used in this Manual In this manual, the following four warning terms are used to signal the four levels of hazard (or seriousness of possible accidents).
  • Page 5 Warranty and After-Sales Service Warranty CHIKUSUI CANYCOM, INC. provides you a warranty through Canycom U.S.A. A copy of this warranty is reproduced in the back of the manual. After-Sales Service Consult your local CANYCOM dealer or our company’s sales department regarding service orders or any questions or problems that may arise when using this machine.

  • Page 6: Table Of Contents

    Contents 1. Safety Safety Labels ........1 Safety Precautions .
  • Page 7 Driving ........18 Starting .
  • Page 8 Engine ........45 Engine Oil .
  • Page 9 After Use Care ....... . . 69 After Normal Use ..........69 After Cold Weather Use .

  • Page 10: Safety

    • Replace these labels immediately if they have been removed, have fallen off or become illegible. Use part number written on the label or shown in this manual to order a replacement label from your CANYCOM representative. View A View B...
  • Page 11 Safety 1. 3670 5138 001 2. 3683 5026 001 3. 3677 5045 001 4. 5116 5362 000 5. 3677 5043 001 DANGER! WARNING! WARNING! WARNING! WARNING! Explosion hazard. Moving fan blades Hot liquids. Burn E l e c t r i c s h o c k Hot surfaces.

  • Page 12: Safety Precautions

    Safety Safety Precautions This section contains safety precautions to follow when operating and maintaining the machine. Read and understand the precautions in this section as well as throughout this manual and follow them when operating or maintaining machine. Failure to follow safety precautions could result in property damage, serious injury or death to the operator or bystanders.

  • Page 13: Preparation

    Safety Preparation • Fuel is highly flammable. See Checking and Filling Fuel, page 16, for important safety information on handling fuel. • Always wear protective footwear, long trousers, hardhat, safety glasses and ear protection when operating or servicing the machine. Proper clothing will minimize the chance of injury.
  • Page 14 Safety • Do not touch the engine, muffler or exhaust pipe while the engine is running or soon after it has stopped. These areas will be very hot and can cause burns. • Do not operate the machine under the influence of alcohol or drugs. Do not operate the machine when you are tired, ill, or not feeling well.
  • Page 15 Safety • Do not make sudden maneuvers. A sudden start, stop, or turn can make the machine lose control and could cause an overturn. Be especially cautious when traveling on soft or wet ground. • Drive at a safe speed, taking into account the surface gradient, surface conditions and load.
  • Page 16 Safety • Drive straight up or down a slope. Avoid turning on a slope. • Avoid driving machine across a slope. • When going over the top of a slope, go slow; an obstacle, a sharp drop, or another vehicle or person could be on the other side of the crest. •...

  • Page 17: Servicing

    Safety Parking • Park the machine on a flat, level and stable surface. Never park on a slope steeper than 15 degrees. Avoid parking on a slope less than 15 degrees. If parking on a slope less than 15 degrees is unavoidable, apply parking brake and block the tracks at the lower end of the machine.
  • Page 18 Safety • Check all fuel lines on a regular basis for tightness and wear. Tighten or repair them as needed. • Do not touch the engine, muffler, or exhaust pipe while the engine is running or soon after it has stopped. These areas will be very hot and can cause burns. •...

  • Page 19: Controls And Components

    Controls and Components Name and Function of Controls Top Cover Left Side Cover Front Cover Fire Extinguisher Upper Hitch Lower Hitch Hydraulics Connectors Lower Hitch Right Side Cover Guide Rail Controls Cover Idler Wheel Step Return Roller Track Roller Sprocket 5116M-0201-010E -10-...
  • Page 20 Controls and Components Normal Model Variable Speed PTO Model 4 5 6 5116M-0201-021E -11-...
  • Page 21 Controls and Components 5116M-0201-030E 1 Throttle Lever ..Throttle Lever is used to control engine speed. 2 Implement Direction ..Implement direction switch changes the rotating direction Switch of implement.
  • Page 22 Controls and Components 12 Automatic Step Levelling . Automatic step levelling switch turns on or off automatic Switch leveling function of step. 13 Manual Step Levelling ..Manual step levelling switch is used to level step manually. Switch 14 Implement Height .

  • Page 23: Specifications

    Specifications Product Specifications · Understand the specifications of this product thoroughly before use. Model and Type CG431 Machine Mass kg (lbs) 1590 (3510) Overall Length mm (in) 3465 (136.4) Overall Width mm (in) 1700 (66.9) Overall Height mm (in) 1405 (55.3)

  • Page 24: Contents Of Tool Bag

    Specifications Model and Type CG431 Main Transmission HST (2 Speed Motor) Steering Twin HST Tranamission Oil Capacity L (US gal) 42 (11.1) Brakes Hydraulic *These specifications are subject to change without notice. Contents of Tool Bag Content Quantitiy Note Operator's Manual...

  • Page 25: Operation

    Operation Preparation Pre-start up Inspection Always perform an inspection before use. Refer to Maintenance Schedule (page 34) for the inspection schedule and procedure. Checking and Filling Fuel • Keep fire and spark away when handling fuel. • Always stop engine before refueling. •...

  • Page 26: Unfolding/Folding Step

    Operation Unfolding/Folding Step • Hold step firmly when folding or unfolding step. Make certain that hands or fingers are not in the way to be caught by step when folding or unfolding. • Make certain that step is securely locked with stopper in either position. Unfolding Step Hold step firmly and pull stopper knob.

  • Page 27: Driving

    Operation Driving Starting • Always start and run engine in a well ventilated place. • Always make certain of the safety of your surroundings when starting engine. Always unfold step and stand on step when starting engine to avoid accident. •...
  • Page 28 Using this machine under such conditions may result in an accident or cause damage to the machine. If you need to use this machine above that altitude, contact your CANYCOM representative. Make sure parking brake switch is in Parking Brake Switch (Parking)] position.
  • Page 29 Operation Make certain safety switch plug is attached. Tie its string to your body. Safety Switch 5116M-0402-030E Make sure control stick is in neutral position. Control Stick 5116M-0402-040E Move throttle lever slightly toward [ (fast)]. Throttle Lever （Irrust indicates Hay Collector Model） 5116M-0402-051E Turn main switch to [ (preheat)] position.
  • Page 30 Operation Turn main switch to [ (start)] position to start engine. Once engine starts, release key Start immediately; switch will automatically return Aux. Transmission Parking Brake Main Switch Implement Translation Switch Drive Center Right to [ | (on)] position. Horn NOTE Start 1.

  • Page 31: Driving

    Operation Driving • Do not allow bystanders to come near machine when driving. • Always make certain of the safety of your surroundings before driving; start slow. • Always make certain of the safety of your surroundings before turning. • Do not make sudden starts, acceralation, change of speed, change of direction, or stop.
  • Page 32 Operation Move throttle lever toward [ (fast)] （Irrust indicates Hay Collector Model） position to increase engine speed. Throttle Lever 5116M-0402-101E Press implement lift switch [UP] to lift Implement Lift Switch(Up) implement off the ground. 5116M-0402-110E Turn parking brake switch to [RUN]. Parking Brake Switch NOTE Main Switch...

  • Page 33: Stopping

    Operation Turning Right Turn Left Turn Twist control stick gradually to a desired direction. Machine turns to the corresponding Control Stick direction. Turning radius can be controled by the amount of twisting. Twisting control stick in the neutral position makes machine spin- Right Turn Left Turn turn on the spot.
  • Page 34 Operation M o v e t h r o t t l e l e v e r t o [ ( s l o w ) ] t o Throttle Lever decrease engine speed. （Irrust indicates Hay Collector Model） 5116M-0402-051E Press implement lift switch [DOWN] to lower Implement Lift Switch (Down)

  • Page 35: Working

    Operation Working • Never place any part of body under implement when implement is running. See implement's manual for safe use. • Always tie string on safety switch to operator's body so that machine stops when operator falls off machine. •...

  • Page 36: Operating Implement

    Operation • Do not use this machine on an incline steeper than 30 degres. • Always use [ (Slow)] mode when working. • Do not turn on an incline, or machine can tip over. • Do not work on a slippery surface. •...
  • Page 37 Operation Use implement lift switch to adjust the Implement Lift Switch implement height. 5116M-0403-020E Use rotation direction switch to choose the Implement Direction Switch direction of implement rotation. Implement Aux. Transmission Parking Brake Main Switch Direction Switch Drive NOTE Normal •...

  • Page 38: Changing Pto Speed (Variable Pto Speed Model Only)

    Operation Changing PTO Speed (Variable PTO Speed Model Only) On Variable Speed PTO model, the PTO speed can be varied to meet requirements for different implements. • Use only the implements that are specifically designed and certified for this machine. •...

  • Page 39: Translating Implement

    Operation Translating Implement With this translation function, the entire implement can be translated to the right by 500mm at the maximum, allowing working on the edge of ditch or bank. • Always make certain of the safety of your surroundings before translating implement.

  • Page 40: Levelling Step

    Operation Levelling Step Step levelling turns step relative to machine to keep it horizontal and provide stable work platform for the operator. • Under normal condition, keep step levelling to [AUTO]. • Pinch hazard: beware of pinch spots when levelling step manually. Keep fingers or hands away of pinch spots.

  • Page 41: Hydraulic Cooling Fan

    Operation Hydraulic Cooling Fan Hydraulic cooling fan automatically reverses at a certain interval to prevent clogging of radiator. It has three operation modes to suite different conditions. • Do not set mode to [1] when working. It may cause overheating. Open top cover and hold it securely with Fan Mode Selector Switch prop (Page 43).

  • Page 42: Fire Extinguisher

    Operation Fire Extinguisher • Read and understand the attached Fire Extinguisher Operator's Manual thoroughly before use. Fire Extinguisher Location Fire extinguisher is attached on the left side of controls cover. 5116M-0404-010E Using Fire Extinguisher Refer to the fire extinguisher operator's manual for its use. -33-...

  • Page 43: Maintenance

    • Perform a pre-startup inspection (PSI) before each use, a monthly inspection once a month, and a yearly inspection once a year. • Some maintenance procedures described below may require special knowledge or tools and instruments. Contact your CANYCOM representative to perform such procedures. Schedule...
  • Page 44 Maintenance Schedule Item Description Note Compression shall be normal Contact your CANYCOM * this may be skipped if running and exhaust representative for √ Compression condition is normal at idle and under inspection. acceleration. Engine base shall be free of cracks or √...
  • Page 45 Cooling Mounting bolts and nuts on cooling fan, duct, System √ and covers shall not be loose or missing. Charge system is working correctly. Contact your CANYCOM Charge √ representative for System inspection. Battery electrolyte level shall be correct.
  • Page 46 Maintenance Schedule Item Description Note Track adjuster shall work normally when Track √ √ filled with a proper amount of grease. Adjuster There shall not be cracks, deformation, damage, or excessive wear on wear parts. In √ √ case of a possible crack, use flaw detector to Track Frame check.
  • Page 47 Maintenance Schedule Item Description Note Shall be firmly and properly mounted. √ √ When a valve is operated, its corresponding cylinder shall move accordingly. when √ √ Control Valve There shall be no leaks in pipes, hoses, √ √ joints, or seals. Shall be free of cracks, deformation, or √...

  • Page 48: List Of Fluids And Lubricants

    Maintenance List of Fluids and Lubricants Item Schedule Grade Cap. Fuel As needed. Diesel Fuel (13.74 US gal) Engine Oil Diesel Engine Oil Fill API rating: CD or better. Inspect daily. Fill as needed. 9.7L SAE rating: 10W-30 Change (10.25US qt) I n i t i a l l y - A f t e r 5 0 h o u r s o f u s e .

  • Page 49: Grease Points

    List of Consumables and Spares • Use only CANYCOM genuine parts when replacement or repair is required. CANYCOM assumes no liability whatsoever if any problem occurs as a result of using any part that is not a genuine CANYCOM part.
  • Page 50 Maintenance Item Part No. Schedule Qty. Fuel System Fuel Filter Cartridge 36640221500 Every 500 hours. Hoses (Fuel) 51160531000 Every 2 years or if defective. 51160532000 Every 2 years or if defective. 51160533000 Every 2 years or if defective. 51160534000 Every 2 years or if defective. 51160538000 Every 2 years or if defective.
  • Page 51 Maintenance Item Part No. Schedule Qty. Hoses (Drive) 51166142000 Every 2 years or if defective. 51166143000 Every 2 years or if defective. 51166144000 Every 2 years or if defective. Electric System Battery 100E41R 36610502000 If defective. Fuse 10A (Red) 09801001004 If defective.

  • Page 52: Body Panels

    Maintenance Body Panels • Do not open engine cover while engine is running. • Cut or pinch hazard exists when removing or installing body panels; beware of sharp edges and pinch points. • Make certain to reinstall panels and closing doors after removing or opening for repairs or inspection.

  • Page 53: Removing Side Covers

    Maintenance Removing Side Covers Pull lower side of side cover to undo lower Side Cover catch. Pull side cover up and away from machine to undo upper catch. 5116M-0504-030E Removing Front Cover Remove side covers on both sides. Front Cover Undo 6 bolts to remove front cover.

  • Page 54: Engine

    Maintenance Engine • Always stop engine and remove key before servicing. • An engine that has been running is very hot. Allow engine to cool before servicing, or severe burns may result. • Keep fire and spark away when handling fuel. Engine Oil •...
  • Page 55 Maintenance Visually check oil level. If it is below lower limit, fill. Lower Limit Upper Limit Visually inspect the condition of oil. If it is dirty or its viscousity is not right, change oil. Install oil level gauge. Close top cover. Level Gauge 5116M-0505-020E Filling...

  • Page 56: Oil Filter

    Maintenance Oil Filter Drain oil. Remove oil filter cartridge with filter wrench. Clean filter base on engine. Oil Filter Cartridge 5116M-0505-050E Prepare new filter cartridge. Coat its oil seal Oil Seal with fresh engine oil. Install cartridge and tighten it fully with hand. Fill oil.
  • Page 57 Maintenance • Maintain sufficient amount of coolant. Insufficient amount of coolant may cause overheating. • Dispose of drained coolant properly. NOTE • Coolant capacity and grade: Page 39. Inspecting Reservoir Tank Park machine on a level surface.Open engine cover. Visually check engine coolant level in reservoir tank.
  • Page 58 Maintenance Remove drain plug to drain coolant. Wash inside radiator with running water. Drain Plug Replace drain plug. 5116M-0505-100E Fill coolant into radiator up to filler. Filler 5116M-0505-110E Change coolant in reservoir tank. Reservoir Tank Run engine for 5 minutes to bleed air. 10.

  • Page 59: Air Cleaner

    Maintenance Air Cleaner • Clean air cleaner element everyday. Dirty cleaner element causes difficult starting, reduces engine performance and shortens engine life. • Clean air cleaner element twice a day when working in extremely dusty environment. • Replace cleaner element if damaged. Open top cover and hold it securely in place Lock Air Cleaner Lid...

  • Page 60: Fan Belt

    Maintenance Fan Belt • Adjust fan belt properly. Loose belt slips and reduces cooling airflow and electricity generated by altornator. Slippage also reduces belt life. Inspecting Open top cover and hold it securely in place with prop. Push in the middle of belt to check amount of bending.

  • Page 61: Fuel System

    Maintenance Fuel System • Stop engine when servicing fuel system. • Keep fire and spark away when handling fuel. • Do not spill fuel. If case fuel is spilt, wipe out immediately. • Dispose of drained fluid properly. Bleeding When air enters into fuel system after it is completely run dry or fuel filter is replaced, it becomes impossible to start engine.

  • Page 62: Fuel Filter Cartridge

    Maintenance Fuel Filter Cartridge Remove controls cover. Fuel Filter Cartridge Remove fuel filter cartridge with oil filter wrench. 5116M-0506-030E Prepare new filter cartridge. Coat its oil seal Oil Seal with fresh fuel. Install cartridge and tighten it fully with hand. Fill fuel and bleed fuel system.

  • Page 63: Hydraulic System

    Maintenance Hydraulic System • Stop engine when servicing hydraulic system. • Allow machine to cool off before servicing. Engine is very hot after operation and may pose a burn hazard. • Dispose of drained fluid properly. Hydraulic Fluid • Maintain sufficient amount of hydraulic fluid in hydraulic system. If there is not sufficient amount of fluid, air can enter into circuit, affecting its operation and reducing efficiency.
  • Page 64 Maintenance Oil Level Sight Glass HIGH Recommended Level 5116M-0507-020E Filling Remove filler cap. Fill specified fluid into filler. Filler Cap Check fluid level. Replace filler cap. 5116M-0507-030E Changing Have an appropriate drain pan. Remove right side cover. Remove drain plug to drain fluid. Replace drain plug.

  • Page 65: Suction Filter

    Maintenance Suction Filter NOTE • Replace suction filters when hydraulic fluid is changed. Drain fluid. Hose Elbow Loosen hose clamp to remove hose from elbow. Remove elbow. 5116M-0507-050E Undo mount bolts to remove suction filter Suction Filter Suction Filter from tank. (Gear Pump side) (Cutting Rotor side) Install new suction filter.

  • Page 66: Return Filter Element

    Maintenance Return Filter Element Loosen hose clamp to remove hose. Undo mount bolts to remove return filter from tank. Return Filter 5116M-0507-070E Loosen set screw and turn holder to remove. Replace element with new one. Replace holder. Tighten set sctew. Element NOTE •...

  • Page 67: Drive Train

    Maintenance Drive Train • Stop engine when servicing drive train. Track • When jacking up machine, hold machine with jack stands securely. Use jack stands with sufficient load rating. • Projection hazard: track adjuster cylinder is highly pressurized. When loosening valve, loosen gradually, or valve can shoot off. Also avoid positioning your body directly against valve or put your head near it.

  • Page 68: Drive Motor Lubricant

    Maintenance A d j u s t t r a c k s o t h a t t h e g a p b e t w e e n track and roller (A) is between 30mm and 40mm (1.18 and 1.57 in) with roller swing horizontal.

  • Page 69: Greasing

    Maintenance NOTE • Fluid capacity and grade: Page 39. Park machine so that drain plug on drive Drain Plug motor is in the lowest position. Have an appropriate drain pan. Remove drain plug to drain lubricant. 5116M-0508-040E Move machine so that drain hole is placed Drain Plug avobe check plug.

  • Page 70: Control Stick

    Maintenance Grease roller swing pivots (4 places). Swing Pivots 5116M-0508-060E Three-Point Hitch Links and Bearings Grease bearings and links on three-point hitch. 5116M-0510-070E Cylinder Pins G r e a s e p i n s o n t h e e n d s o f h y d r a u l i c cylinder.

  • Page 71: Electrical System

    Maintenance Adjust rods (F) so that links (E) on both ides are parallel when control stick (D) is vertical. NOTE • Make sure there is no leak from hose joints or elbows. Adjust rods (G) so that links (B) start to move at the same time when control stick (D) is tilted forward and backward.
  • Page 72 Maintenance • Battery fluid (diluted sulfic acid) is corrosive and causes severe burns. Be extremeley cautious when handling battery fluid. If battery fluid is spilt on clothes, immediately rinse with plenty of water. If spilt on skin or in an eye, immediately rinse with plenty of water and promptly consult a physician.

  • Page 73: Charging Battery

    Maintenance Charging Battery • Never charge battery when the fluid level is below [Lower Level]. Charging battery with insufficient fluid may shorten battery life or cause an explosion. • Battery fluid (diluted sulfic acid) is corrosive and causes severe burns. Be extremeley cautious when handling battery fluid.

  • Page 74: Fuses

    Maintenance Park machine on a level surface. + Terminal - Terminal Remove right side cover. Remove negative (-) cable from terminal. Remove positive (+) cable from terminal. Remove battery from machine. 5116M-0509-030E Follow instructions in battery charger operator's manual to charge battery. When charge is complete, install battery to machine.

  • Page 75: Slow-Blow Fuses

    Maintenance Slow-Blow Fuses • If a slow-blow fuse blows, investigate the cause and repair it before replacing. • Always replace a slow^blow fuse with the one of the correct amperage. Open top cover and hold it securely in place Fuse Box with prop.

  • Page 76: Imprement

    Maintenance Implement Attaching/Detaching Implement • Park machine on a level surface when attaching or detaching implement. • Do not go under implement. • Always release residual pressure of hydraulic components when detaching implement, or oil under high pressure may leak and penetrate through skin and cause injury upon contact.
  • Page 77 Maintenance Remove link pins and pins. (2 places on both Lever sides.) Fold down lever to unlock. 5116M-0510-100E Lower link to unhook. Drive backwards to remove implement. Joint 5116M-0510-110E -68-...

  • Page 78: After Use Care

    Maintenance After Use Care • Do not wash engine, control panel, electrical parts, or tank caps with air breather with running water; water may enter inside and cause rust or damage. • Clean machine after use; leaving dirt or foreign objects may cause damage. •...

  • Page 79: Storage

    Maintenance Storage • Fire hazard; do not store machine where there is a possiblity of ignition. • Do not wash engine or control panel with running water; water may enter inside and cause rust or damage. • Clean machine before storage; leaving dirt or foreign objects may cause rust or damage.

  • Page 80: Troubleshooting

    Troubleshooting chart below. If the malfunction or abnormal condition is not listed in the chart, or the suggested measure does not solve the problem, consult with your CANYCOM representative. • Some corrective measures listed below require special knowledge and/or equipment.
  • Page 81 Troubleshooting Area Malfunction Possible Cause Corrective Measure Ref. Electrical malfunction →Please contact your CANYCOM representative. Engine does not stop Other (other than the →Please contact above). your CANYCOM representative. Bad fuel →Change fuel. Wrong oil (wrong →Change for correct Page 45 viscosity) oil.
  • Page 82 →Clean or replace the Page 50 air cleaner. Excessive fuel Other (other than the →Please contact consumption above). your CANYCOM representative. Clogged air cleaner. →Clean or replace the Page 50 air cleaner. Black smoke comes Other (other than the →Please contact above).
  • Page 83 Control stick is not →Adjust. Page 61 Machine does not run properly adjusted. straight Other (other than the →Please contact above). your CANYCOM representative. Drive Track is derailed. →Reinstall and adjust Page 58 Train track. Roller, sprocket, or →Tighten the loose Machine vibrates idler is loose.
  • Page 84 "Working" to operate Implement does not the machine. If run. problem persists, Implement please contact Drive your CANYCOM representative. Implement vibrates Foreign object is →Untangle. tangled. excessively when it is Other (other than the →Please contact above).

  • Page 85: Transporting

    Transporting Hauling Loading and Unloading • Park transporter (truck) on a level ground. Always use chocks to secure wheels. • Do not allow bystandars to come close to machine or transporter when loading or unloading machine. • Use only the loading ramps with sufficient strength (to withstand the combined weight of machine and operator), width (more than 1.2 times the width of track), and length (more than 4 times the height of loading deck of transporter), and have anti-slip ramp surfaces.
  • Page 86 Transporting Height Note: Typical configuration with mower implement (CG431 Mower) shown. 5116M-0701-010E Loading to Transporter Park transporter. Secure wheels with chocks. Place loading ramps. Secure hooks of ramps firmly and flush with loading deck. Lift up implement. Set auxiliary transmission switch to [ (slow)].

  • Page 87: Hoisting And Towing

    Transporting Hoisting • Hoisting may require appropriate training or licence. Consult with your local authority. • Use hoisting sling of sufficient strength. Always use slings of the same length when more than one is used. • Pay attention to the balance and the location of the center of gravity of machine.
  • Page 88 NOISE LEVEL Model Engine Type Type Speed rpm CG431 Kubota V2203 2,800 rpm 98 dB (A) NOISE LEVEL evaluated based on factory standard. VIBRATION Engine Model Rated revolution Steering lever Seat CG431 2,800 rpm 3.0 m/s 3.0 m/s VIBRATION evaluated based on factory standard.
