ENGINE MOUNT INSTALLATION.

1) Locate the items necessary to install the
engine mount included with your model. .
M4x30mm.
2) Use four M4x30mm head bolts and four
4mm washers to attach the engine mount rails
to the firewall. Tighten the screws . Make sure
to use threadlock on the screws to help
prevent them from vibrating loose.
ENGINE 0.72 : 4 STROKE
Thread locker glue
INSTALLING THE STOPPER ASSEMBLY.
1) Using a modeling knife, carefully cut
off the rear portion of one of the 3 nylon tubes
leaving 1/2" protruding from the rear of the
stopper. This will be the fuel pick up tube.
2) Using a modeling knife, cut one length
of silicon fuel line. Connect one end of the line
to the weighted fuel pick up and the other end
to the nylon pick up tube.
www.seagullmodels.com
A
Vent tube.
Fuel fill tube.
3) Carefully bend the second nylon tube
up at a 45º angle. This tube is the vent tube.
4) Test fit the stopper assembly into the
tank. It may be necessary to remove some of
the flashing around the tank opening using a
modeling knife. If flashing is present, make
sure none falls into the tank.
5) With the stopper assembly in place,
the weighted pick-up should rest away from
the rear of the tank and move freely inside the
tank. The top of the vent tube should rest just
below the top of the tank. It should not touch
the top of the tank.
