CAPA841/842 Capa Board
1.1

Features

®
 CAPA841- Intel
®
 CAPA842 - Intel
 1 DDR3L SO-DIMM supports up to 8 GB memory capacity
 4 USB 2.0 ports
 4 COM ports

2 PCI-Express Mini Card
 +12V only DC-in supported
 Wide operating temperature supported
1.2

Specifications

 CPU
 CAPA841
®
- Intel Atom
®
- Intel Atom
 CAPA842
®
- Intel Celeron
®
- Intel Celeron
 Thermal Solution

Passive.
 Operating Temperature
 CAPA841: -40°C~80°C or -20
 CAPA842: -20
 BIOS

American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS.
 16Mbit SPI Flash, DMI, Plug and Play.
 PXE Ethernet Boot ROM.
 System Memory
 One 204-pin unbuffered DDR3L SO-DIMM socket.
 Maximum up to 8GB DDR3L 1333/1066MHz memory.
 Onboard Multi I/O
 Controller: Nuvoton NCT6106D.
 Serial Ports: Two ports for RS-232/422/485 and two ports for RS-232.

Serial ATA

One SATA-300 connector.

One CFast™ socket.
 mSATA supported (Optional).
 USB Interface
 Four USB ports with fuse protection and complies with USB Spec. Rev. 2.0.
 Display

One 15-pin D-Sub as VGA connector.
 One 2x20-pin connector for 18/24-bit single/dual channel LVDS and one 8-pin
inverter connector. LVDS resolution is up to 1920x1200 in 24-bit dual channels.
 One HDMI.
2
TM
Atom quad core E3845 (1.91GHz) and dual core E3827 (1.75GHz)
®
Celeron quad core J1900 (2GHz) and dual core N2807 (1.58GHz)
TM
quad core E3845 1.86GHz.
TM
dual core E3827 1.75GHz.
®
quad core J1900 2GHz.
®
dual core N2807 1.58GHz.
o
C~80
o o
C~-70 C.
o
C.
