13.6 Remote Notification Features

Remote Notification provides the UPS with the capability to utilize a standard
off-the-shelf PC modem as a telephone interface. The features provided by this
option are as follows:
•
Call out to a remote terminal or pager based on programmable events and
alarms.
•
Four separate, programmable notification groups (phone numbers).
•
Automatic answering (user configurable) for access to the Terminal mode of
the UPS.
•
Remote and local ability to clear Call Out alarms and events.
•
Error detection and correction for misconfigured and disconnected modems.

13.7 Terminal Mode

In Terminal Mode, the user can request the following:
NOTE: The brackets ([ ]) in the following bullets indicate standard keyboard
characters.
To use a key combination, hold down the Escape key and press the indicated letter
key.
• Display UPS Control Panel by pressing and holding [ESC], then press [V].
•
Display Event History by pressing and holding [ESC], then press [H].
•
Display Node Bits Setup by pressing and holding [ESC], then press [N].
• Display any new event by pressing and holding [ESC], then press [L].

13.7.1 Display UPS Control Panel

When this function is invoked, a facsimile of the UPS Control Panel is displayed on
the terminal screen. All controls are functional and will control the UPS remotely.
The only exception is the Load Off control which requires the operator to press and
hold the local control for two seconds to shutdown the UPS.
To remotely control the UPS or view UPS information, use the escape key legend
to control the function normally controlled by the Control Panel softkeys. Refer to
Chapter 9 "Using the Control Panel" for instructions on navigating the control
panel.
Figures 13---3 through 13---18 show typical screens using this function.
