Identification - Grizzly G1014Z Owner's Manual

9" sanding
disc
2" dust
port
miter
gauge
angle scale
angle scale
lock Knob
support
rod
on/oFF
switch w/
disabling
Key
Cabinet
Foot
If you have never used this type of machine or equipment before, WE STRONGLy RECOMMEND
that you read books, review industry trade magazines, or get formal training before beginning
any projects. Regardless of the content in this section, Grizzly Industrial will not be held liable
for accidents caused by lack of training.
model g1014z/g1014zX (mfg. 11/07+)

Identification

idler roller
platen
Work
table
pulley
Cover
2 ⁄ " dust
1
2
port
door
handle
figure 1. g1014zX identification.
NOTICE
Back
idler roller
stop
guard
tracking
Knob
Quick
release
tension
lever
power Cord
drive
sanding
roller
Belt
