ABOUT THE INSTRUCTIONS

The Full and Basic manuals are described based on
the following manner.
" " (Quotation marks):
Used to indicate icons, setting items, and screen*
titles displayed on the screen.
[ ] (brackets):
Used to indicate keys.
* The screen titles are also indicated in uppercase letters.
(Example: FUNCTION screen)
Routes to the set modes and setting screens
Routes to the set mode, setting screen and the setting
items are described in the following manner.
» SET > Display > Display Type
MENU
Instruction example
Detailed instruction
1. Push .
MENU
Push
• Opens the MENU screen.
2. Touch [SET].
MENU screen
• Opens the SET screen.
3. Rotate
MULTI
"Display."
SET screen
4. Rotate
MULTI
"Display Type."
DISPLAY screen
"Display Type" screen
iv
, and then push
MULTI
, and then push
MULTI
to select
Rotate
Push
to select
Rotate
Push
