1.4 Programming the microswitches

The Teldat T200 has a block of 8 microswitches, useful for maintenance tasks and testing. Here they are only used
to ignore the configuration or establish the default configuration (where there is a default configuration file
config.def).
This block is normally found on the underside of the Teldat t200. It should not be handled by the user unless it is ne-
cessary to re establish the default configurations.
Note
All microswitches must be in the OFF position to ensure correct functionality.
1.4.1 Procedure to ignore the configuration, or establish the default configura-
tion
Follow these steps when you have to reject the whole router configuration (for instance, if you cannot remember the
password):
• Turn off the device by means of the ON/OFF switch.
• Using a screwdriver, move microswitch 5 to the ON position.
• Turn the router on with the ON/OFF switch.
When the device is switched on, a message similar to the one shown below will appear on the configuration console:
**************************************************
**************************************************
**************************************************
BOOT CODE VERSION: 02.09
gzip Feb 10 2009 10:10:22
P.C.B.: B2 MASK:0C10
Teldat T200 Router Family
OFF: Switch(es) not available.
RED: Active Switch(es), there are no active devices connected.
GREEN: Active Switch(es), there is at least one active device connected.
Blinking: "heartbeat" .
Not used in the current version of the device.
Not used in the current version of the device.
Multistandard Serial Interface
OFF: Port has not initialized.
RED: Port has initialized.
YELLOW: Establishing the link.
GREEN: Communications established.
Not used in the current version of the device.
Feb 10 2009 10:10:22
Microcode:00E1
