E R R O R C O D E S
When power is applied, the unit will automatically enter a "Motor Reset" mode,
which brings all the internal motors to a home position. If there is an internal problem
with one or more of the motors, an error code (see below) will flash on the control
display.
Specifications and features are subject to change without any prior written notice.
ERROR CODE
TILT Er
PAN Er
ELATION© ACL 360 MATRIX™
E R R O R
The TILT movement is not located in the default position after the reset.
This message will appear after a fixture reset if the magnetic-indexing circuit
malfunctions (sensor failed or magnet is missing) or there is a motor failure
(defective motor or defective motor IC drive on main PCB). This error may also
be displayed if the head was blocked during a reset function
The PAN movement is not located in the default position after the reset.
This message will appear after a fixture reset if the magnetic-indexing circuit
malfunctions (sensor failed or magnet is missing) or there is a motor failure
(defective motor or a defective motor IC drive on the main PCB). This error
may also be displayed if the head/yoke was blocked during a reset function.
28
w w w . e l a t i o n l i g h t i n g . c o m
C O D E S
DESCRIPTION
ACL 360 MATRIX™ User Manual Ver 1
