C O N T E N T S General Information Warranty Safety Instructions General Guidelines Fixture Overview Fixture Installation Fixture Menu DMX Channel Functions And Values Error Codes Cleaning and Maintenance Technical Specifications Optional Accessories ACL 360 MATRIX™ User Manual Ver 1...
Please do not discard the shipping carton in the trash. Please recycle whenever possible. BOX CONTENTS (2) Omega Brackets (1) powerCON Cable Manual & Warranty Card ACL 360 MATRIX™ User Manual Ver 1...
Page 5
You may also visit us on the web at www.elationlighting.com any comments or suggestions. For service related issue please contact Elation Professional®. ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST...
No accessories should be shipped with the product. If any accessories are shipped with the product, Elation Professional® shall have no liability what so ever for loss and/or or damage to any such accessories, nor for the safe return thereof.
Do not operate this fixture if the power cord has become frayed, crimped and/or damaged. If the power cord is damaged, replace it immediately with a new one of similar power rating. ACL 360 MATRIX™ User Manual Ver 1...
Use the original packaging and materials to transport the fixture in for service. DO NOT TOUCH the housing bare-hand during its operation. Turn OFF the power and allow approximately 15 minutes for the fixture to cool down before replacing or serving. ACL 360 MATRIX™ User Manual Ver 1...
F I X T U R E O V E R V I E W LCD Control Display Fuse DC Switch powerCON IN UP, DOWN, LEFT, RIGHT, ENTER Buttons 3pin, 5pin DMX IN MODE Button 3pin, 5pin DMX OUT NET IN/OUT (RJ45 Ethernet) powerCON OUT ACL 360 MATRIX™ User Manual Ver 1...
10 times the weight of the fixture. Fixture installation must always be secured with a secondary safety attachment, such as an appropriate safety cable. Never stand directly below the device when mounting, removing or servicing. ACL 360 MATRIX™ User Manual Ver 1...
Page 11
S A F E T Y C A B L E Always use a Safety Cable whenever installing this fixture in a suspended environment to ensure the fixture will not drop if the clamp fails. ACL 360 MATRIX™ User Manual Ver 1...
Page 12
The fixture provides a built-in rigging point for a safety cable. Be sure to only use the designated rigging point for the safety cable and never secure a safety cable to a carrying handle. ACL 360 MATRIX™ User Manual Ver 1...
OFF automatically about 1 minute from the last button press. INFORMATION DISPLAYED DURING INITIAL POWER ON When the fixture is initially powered ON, the display shows the following information: Software Update Motor Reset Please Wait... Please Wait... ACL 360 MATRIX™ User Manual Ver 1...
Page 14
Error. Info Reset Error Message Model. Info ACL 360 Bar Display Model Name 1U01: ≥V1.12 Software Version 2U01: ≥V1.06 Software Versions 3U01: ≥V1.12 Error Info Error Record 1 ~ Error Record 10 Pan..ACL 360 MATRIX™ User Manual Ver 1...
Page 15
(8), and then set Channel 3 to a value of (164). (256+164=420) 5. After setting Channel 3 to the desired DMX address value, wait for approximately 20 seconds for the fixture to complete the address reset function. ACL 360 MATRIX™ User Manual Ver 1...
Page 16
RDM. The number and type of RDM parameters depend on the RDM controller being used. Function - Dim Curve Select desired DIMMER MODE (Standard, Stage, TV, Architectural, Theatre). ACL 360 MATRIX™ User Manual Ver 1...
Page 17
Because calibration is an extremely delicate procedure, instructions on performing this action are left out of this manual. For a first time calibrator, please contact our customer support team for step-by-step instructions. ACL 360 MATRIX™ User Manual Ver 1...
0 to 100% *RED - LED 2 0-255 0 to 100% *GREEN - LED 2 0-255 0 to 100% *BLUE - LED 2 0-255 0 to 100% *WHITE - LED 2 0-255 0 to 100% ACL 360 MATRIX™ User Manual Ver 1...
Page 19
0 to 100% *RED - LED 7 0-255 0 to 100% *GREEN - LED 7 0-255 0 to 100% *BLUE - LED 7 0-255 0 to 100% *WHITE - LED 7 0-255 0 to 100% ACL 360 MATRIX™ User Manual Ver 1...
Page 20
0 to 100% *RED - LED 12 0-255 0 to 100% *GREEN - LED 12 0-255 0 to 100% *BLUE - LED 12 0-255 0 to 100% *WHITE - LED 12 0-255 0 to 100% ACL 360 MATRIX™ User Manual Ver 1...
Page 21
0 to 100% *RED - LED 17 0-255 0 to 100% *GREEN - LED 17 0-255 0 to 100% *BLUE - LED 17 0-255 0 to 100% *WHITE - LED 17 0-255 0 to 100% ACL 360 MATRIX™ User Manual Ver 1...
Page 22
0 to 100% *RED - LED 22 0-255 0 to 100% *GREEN - LED 22 0-255 0 to 100% *BLUE - LED 22 0-255 0 to 100% *WHITE - LED 22 0-255 0 to 100% ACL 360 MATRIX™ User Manual Ver 1...
Page 23
0 to 100% *RED - LED 25 0-255 0 to 100% *GREEN - LED 25 0-255 0 to 100% *BLUE - LED 25 0-255 0 to 100% *WHITE - LED 25 0-255 0 to 100% ACL 360 MATRIX™ User Manual Ver 1...
Page 24
COLOR MACRO 24 97-100 COLOR MACRO 25 101-104 COLOR MACRO 26 105-108 COLOR MACRO 27 109-112 COLOR MACRO 28 113-116 COLOR MACRO 29 117-120 COLOR MACRO 30 121-124 COLOR MACRO 31 125-128 COLOR MACRO 32 ACL 360 MATRIX™ User Manual Ver 1...
Page 25
0-31 LEDs OFF 32.63 LEDs ON 64-95 Strobe Effect SLOW to FAST 96-127 LEDs ON 128-159 Pulse Effect in Sequences 160-191 LEDs ON 192-223 Random Strobe Effect SLOW to FAST 224-255 LEDs ON ACL 360 MATRIX™ User Manual Ver 1...
Page 26
PROGRAM MACRO 25 251-255 Gradient Effect AUTO PROGRAM MACRO SPEED 0-255 Auto Program Macro Speed SLOW to FAST DIMMING CURVE MODES 0-20 STANDARD 21-40 STAGE 41-60 61-80 ARCHITECTURAL 81-100 THEATRE 101-255 Default to Unit Setting ACL 360 MATRIX™ User Manual Ver 1...
Page 27
Internal Program 3 (scene17~24 of EEPROM) 160-179 Internal Program 4 (scene25~32 of EEPROM) 180-199 Internal Program 5 (scene33~40 of EEPROM) 200-219 Internal Program 6 (scene41~48 of EEPROM) 220-239 Internal Program 7 (scene49~56 of EEPROM) 240-255 NO FUNCTION ACL 360 MATRIX™ User Manual Ver 1...
(sensor failed or magnet is missing) or there is a motor failure (defective motor or a defective motor IC drive on the main PCB). This error may also be displayed if the head/yoke was blocked during a reset function. ACL 360 MATRIX™ User Manual Ver 1...
Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized Elation service technician. Should you need any spare parts, please order genuine parts from your local Elation dealer.
Page 30
5F to 113°F (-15°C to 45°C) APPROVALS / RATINGS CE | IP30 Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. ACL 360 MATRIX™ User Manual Ver 1...
Page 31
70,370 6,537 54,413 5,055 40,505 3,763 29,722 2,761 FULL ON Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. ACL 360 MATRIX™ User Manual Ver 1...
. e l a t i o n l i g h t i n g . c o m DIMENSIONAL DRAWINGS Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. ACL 360 MATRIX™ User Manual Ver 1...
Page 33
5’ (1.5m) CAT6 EtherCON Cable PLC3 3 ft. (1m) PowerCON PRO Link Cable AC3PDMX5PRO 5 ft. (1.5m) 3pin PRO DMX Cable AC5PDMX5PRO 5 ft. (1.5m) 5pin PRO DMX Cable Additional Cable Lengths Available ACL 360 MATRIX™ User Manual Ver 1...
