  • Page 1 VOLT Q5E SIX PACK™ user manual    ...

  • Page 2: Volt Q5E™ User Manual Ver

    Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040 323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com Elation Professional B.V.

  • Page 3: Table Of Contents

    w w w . e l a t i o n l i g h t i n g . c o m C O N T E N T S General Information Warranty Safety Instructions General Guidelines Fixture Overview Battery Charging Fixture Installation Understanding DMX...

  • Page 4: General Information

    O P T I O N A L C O R R O S I O N - R E S I S T A N T C O A T I N G Optional Corrosion-Resistant Coatings may be available for this fixture. Please consult your Elation Professional sales representative for details. VOLT Q5E™ User Manual ver 2...
  • Page 5 You may also visit us on the web at www.elationlighting.com any comments or suggestions. For service related issue please contact Elation Professional®. ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST...
  • Page 6 w w w . e l a t i o n l i g h t i n g . c o m WARRANTY REGISTRATION Please fill out the enclosed warranty card to validate your purchase. All returned service items whether under warranty or not, must be freight pre-paid and accompany a return authorization (R.A.) number.

  • Page 7: Warranty

    No accessories should be shipped with the product. If any accessories are shipped with the product, Elation Professional® shall have no liability what so ever for loss and/or or damage to any such accessories, nor for the safe return thereof.

  • Page 8: Safety Instructions

    w w w . e l a t i o n l i g h t i n g . c o m S A F E T Y I N S T R U C T I O N S ™...

  • Page 9: General Guidelines

    w w w . e l a t i o n l i g h t i n g . c o m G E N E R A L G U I D E L I N E S •...

  • Page 10: Fixture Overview

    w w w . e l a t i o n l i g h t i n g . c o m F I X T U R E O V E R V I E W LED Lens LCD Menu Display MODE/ESC Button UP Button...

  • Page 11: Battery Charging

    w w w . e l a t i o n l i g h t i n g . c o m B A T T E R Y C H A R G I N G ™ The VOLT Q5E internal rechargable Lithium-Ion battery provides up to 7 hours of operation at FULL ON 100% intensity.

  • Page 12: Fixture Installation

    w w w . e l a t i o n l i g h t i n g . c o m F I X T U R E I N S T A L L A T I O N F L A M M A B L E M A T E R I A L W A R N I N G Keep fixture at least 5.0 ft (1.5m) away from any flammable materials, decorations, pyrotechnics, etc.
  • Page 13 w w w . e l a t i o n l i g h t i n g . c o m CLAMP MOUNTING ™ The VOLT Q5E provides a unique mounting bracket assembly that integrates the bottom of the base, the included Omega Bracket and safety cable rigging point in one unit (see the illustration below).
  • Page 14 w w w . e l a t i o n l i g h t i n g . c o m MOUNTING POINTS • Overhead mounting requires extensive experience, including amongst others calculating working load limits, installation material being used, and periodic safety inspection of all installation material and the device.

  • Page 15: Understanding Dmx

    w w w . e l a t i o n l i g h t i n g . c o m U N D E R S T A N D I N G D M X DMX-512 DMX is short for Digital Multiplex.
  • Page 16 w w w . e l a t i o n l i g h t i n g . c o m DMX-512 CONTROLLER CONNECTION Connect the provided XLR cable to the female XLR output of your controller and the other side to the male 3pin input of the VOLT Q5E™.
  • Page 17 w w w . e l a t i o n l i g h t i n g . c o m DMX ADDRESSING All fixtures should be given a DMX starting address when using a DMX controller, so the correct fixture responds to the correct control signal.

  • Page 18: Fixture Menu

    w w w . e l a t i o n l i g h t i n g . c o m F I X T U R E M E N U ON-BOARD SYSTEM MENU The VOLT Q5E™ comes with an easy to navigate system menu. The next sections will cover how to access each menu function.
  • Page 19 . e l a t i o n l i g h t i n g . c o m ELATION© VOLT Q5E™ S Y S T E M M E N U Specifications and features are subject to change without any prior written notice.
  • Page 20 w w w . e l a t i o n l i g h t i n g . c o m FuncMode Address Define desired DMX address via the Control Panel. ValuDisp Display DMX 512 value of each channel. SetSlave Define fixture slave mode (Slave1, Slave2, Slave3).
  • Page 21 w w w . e l a t i o n l i g h t i n g . c o m Persnal Stat Set Addr DMX When ON, define the desired DMX address via an external controller. 1. Connect the fixture to the external controller and power ON. 2.
  • Page 22 w w w . e l a t i o n l i g h t i n g . c o m Man Hold WDMX Control the functionality of the internal wireless WDMX receiver. ResetDef When ON, all factory settings are restored. ManCntrl ManCntrl Select and manually test and fine adjust each individual channel function...
  • Page 23 w w w . e l a t i o n l i g h t i n g . c o m EDIT PROGRAM – Record Controller – Working With Built In Programs A Master unit can send up to 3 different data groups to the Slave units, i.e. a Master unit can start 3 different Slave units, which run 3 different programs.
  • Page 24 w w w . e l a t i o n l i g h t i n g . c o m EDIT PROGRAM – Record Controller – Working With Built-In Program [continued] 3. Program Selection for Auto Pro Part •...
  • Page 25 w w w . e l a t i o n l i g h t i n g . c o m EDIT PROGRAM – Record Controller – Working With Built-In Program [continued] Example: Prog 2 includes scenes: 10, 11, 12, & 13 Prog 4 includes scenes: 8, 9, &...

  • Page 26: Internal Wireless Dmx Receiver Set Up

    I N T E R N A L W I R E L E S S D M X R E C I E V E R ( E W D M X ) The VOLT Q5E™ is equipped with an internal Elation Wireless DMX Receiver, which is fully compatible with an Elation Wireless DMX System.
  • Page 27 w w w . e l a t i o n l i g h t i n g . c o m CLEARING EWDMX TRANSMITTER LINK • Access the fixture’s main menu and toggle to the “PERSNAL” menu, then access the “WDMX”...

  • Page 28: Dmx Channel Functions And Values

    D M X C H A N N E L F U N C T I O N S A N D V A L U E S ELATION© VOLT Q5E™ DMX Channel Values / Functions VERSION 2 (12 DMX Channels)
  • Page 29 . e l a t i o n l i g h t i n g . c o m ELATION© VOLT Q5E™ DMX Channel Values / Functions VERSION 2 (12 DMX Channels) Doc Date 2/6/2015 Soft Ver ≥1.0.3...

  • Page 30: Cleaning And Maintenance

    Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized Elation service technician. Should you need any spare parts, please order genuine parts from your local Elation dealer.

  • Page 31: Technical Specifications

    w w w . e l a t i o n l i g h t i n g . c o m T E C H N I C A L S P E C I F I C A T I O N S FEATURES IP65 Rated 9°...

  • Page 32: Photometric Data

    w w w . e l a t i o n l i g h t i n g . c o m PHOTOMETRIC DATA Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. VOLT Q5E™...

  • Page 33: Optional Accessories

    w w w . e l a t i o n l i g h t i n g . c o m VOLT Q5™ ROAD CASE DIMENSIONAL DRAWINGS O P T I O N A L A C C E S S O R I E S ORDER CODE ITEM TRIGGER CLAMP Heavy Duty Wrap Around Hook Style Clamp...
