Elation ACL 360 MATRIX User Manual page 26

DMX Channel Values / Functions Version 1 (115 DMX Channels)
Specifications are subject to change without any prior written notice.
*Pixel control position depends on the specific Pan/Tilt position of the head.
MODE / CHANNEL
BASIC STAND EXTEND
11 13 109
12 14 110
13 15 111
14 16 112
15 17 113
ELATION© ACL 360 MATRIX™
VALUE
DIMMER INTENSITY
0-255 Intensity 0 to 100%
DIMMER INTENSITY FINE
0-255 Dimmer Intensity FINE Adjustment
AUTO PROGRAM MACROS
0 NO FUNCTION
1-10 PROGRAM MACRO 01
11-20 PROGRAM MACRO 02
21-30 PROGRAM MACRO 03
31-40 PROGRAM MACRO 04
41-50 PROGRAM MACRO 05
51-60 PROGRAM MACRO 06
61-70 PROGRAM MACRO 07
71-80 PROGRAM MACRO 08
81-90 PROGRAM MACRO 09
91-100 PROGRAM MACRO 10
101-110 PROGRAM MACRO 11
111-120 PROGRAM MACRO 12
121-130 PROGRAM MACRO 13
131-140 PROGRAM MACRO 14
141-150 PROGRAM MACRO 15
151-160 PROGRAM MACRO 16
161-170 PROGRAM MACRO 17
171-180 PROGRAM MACRO 18
181-190 PROGRAM MACRO 19
191-200 PROGRAM MACRO 20
201-210 PROGRAM MACRO 21
211-220 PROGRAM MACRO 22
221-230 PROGRAM MACRO 23
231-240 PROGRAM MACRO 24
241-250 PROGRAM MACRO 25
251-255 Gradient Effect
AUTO PROGRAM MACRO SPEED
0-255 Auto Program Macro Speed SLOW to FAST
DIMMING CURVE MODES
0-20 STANDARD
21-40 STAGE
41-60 TV
61-80 ARCHITECTURAL
81-100 THEATRE
101-255 Default to Unit Setting
26
w w w . e l a t i o n l i g h t i n g . c o m
FUNCTION
ACL 360 MATRIX™ User Manual Ver 1
