Elation ACL 360 MATRIX User Manual page 27

DMX Channel Values / Functions Version 1 (115 DMX Channels)
Specifications are subject to change without any prior written notice.
*Pixel control position depends on the specific Pan/Tilt position of the head.
MODE / CHANNEL
BASIC STAND EXTEND
16 18 114
17 19 115
ELATION© ACL 360 MATRIX™
VALUE
PAN / TILT MOVEMENT SPEED
0-225 MAX to MIN SPEED
226-235 Blackout By Movement
236-255 NO FUNCTION
LAMP ON/OFF, RESET, INTERNAL PROGRAMS
0-79 Normal
80-84 ALL Motor Reset
85-99 NO FUNCTION
100-119 Internal Program 1 (scene1~8 of EEPROM)
120-139 Internal Program 2 (scene9~16 of EEPROM)
140-159 Internal Program 3 (scene17~24 of EEPROM)
160-179 Internal Program 4 (scene25~32 of EEPROM)
180-199 Internal Program 5 (scene33~40 of EEPROM)
200-219 Internal Program 6 (scene41~48 of EEPROM)
220-239 Internal Program 7 (scene49~56 of EEPROM)
240-255 NO FUNCTION
