D M X C H A N N E L F U N C T I O N S A N D V A L U E S
DMX Channel Values / Functions Version 1 (115 DMX Channels)
Specifications are subject to change without any prior written notice.
*Pixel control position depends on the specific Pan/Tilt position of the head.
MODE / CHANNEL
BASIC STAND EXTEND
1 1
2
2 3
4
3 5
4 6
5 7
6 8
7 9
8 10
ELATION© ACL 360 MATRIX™
VALUE
PAN MOVEMENT [8 BIT]
1
0-255 PAN Movement 630/540
PAN FINE MOVEMENT [16 BIT]
2
0-255 Fine Control of PAN Movement
TILT MOVEMENT [8 BIT]
3
0-255 TILT Movement
TILT MOVEMENT [16 BIT]
4
0-255 Fine Control of TILT Movement
PAN CONTINUOUS MOVEMENT
0-127 NO FUNCTION
5 128-189 PAN Clockwise from FAST to SLOW
190-193 NO Rotation
194-255 PAN Counter-Clockwise from SLOW to FAST
TILT CONTINUOUS MOVEMENT
0-127 NO FUNCTION
6 128-189 TILT Clockwise from FAST to SLOW
190-193 NO Rotation
194-255 TILT Counter-Clockwise from SLOW to FAST
RED (ALL LEDs)
0-255 0 to 100%
GREEN (ALL LEDs)
0-255 0 to 100%
BLUE (ALL LEDs)
0-255 0 to 100%
WHITE (ALL LEDs)
0-255 BLUE FINE Adjustment
*RED - LED 1
7
0-255 0 to 100%
*GREEN - LED 1
8
0-255 0 to 100%
*BLUE - LED 1
9
0-255 0 to 100%
*WHITE - LED 1
10
0-255 0 to 100%
*RED - LED 2
11
0-255 0 to 100%
*GREEN - LED 2
12
0-255 0 to 100%
*BLUE - LED 2
13
0-255 0 to 100%
*WHITE - LED 2
14
0-255 0 to 100%
w w w . e l a t i o n l i g h t i n g . c o m
FUNCTION
18
